Product Overview
The Schneider TM5ACLPR1 is a Right Side Connector Module from the TM5 modular I/O system. It is designed to provide secure and efficient termination من the I/O bus at the rightmost end من the configuration. Compact and lightweight, it ensures a clean and reliable installation in automation and machine control environments.
Technical Specifications
| Parameter | الوصف |
|---|---|
| Product Type | Right Side Connector Module |
| Series | Modicon TM5 |
| Mounting Type | DIN Rail |
| Function | Terminates TM5 I/O Bus |
| Compatibility | TM5 System Modules |
| Dimensions (W x H x D) | 16 x 53 x 105 mm |
| الوزن | 0.025 kg |
| Operating Temperature | -25°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
Applications
-
Modular machine control systems
-
Distributed I/O configurations
-
Packaging and material handling equipment
-
Industrial automation enclosures
-
Automotive production lines
-
Food and beverage machinery
Key Advantages
-
Compact Design: حفظs space in control cabinets
-
Ease من Installation: Simple clip-on to DIN rail
-
Reliable Bus Termination: Ensures signal integrity
-
Modular Flexibility: الدعمs scalable architecture
-
Robust Construction: Operates in harsh industrial environments
الأسئلة الشائعة (FAQ)
Q1: What is the function من the TM5ACLPR1 module?
A1: It acts as a termination point on the right side من a TM5 I/O configuration to close the bus system properly.
Q2: Is it necessary to use TM5ACLPR1 in every TM5 system?
A2: Yes, it must be installed at the end من the I/O configuration to ensure correct communication and termination.
Q3: Can TM5ACLPR1 be used with TM7 modules?
A3: No, TM5ACLPR1 is specifically designed for the TM5 system and is not compatible with TM7 modules.
Q4: What type من environment is TM5ACLPR1 suitable for?
A4: It’s suitable for industrial environments, within temperature ranges from -25°C to +55°C.
Q5: Does TM5ACLPR1 require power supply?
A5: No, it does not require power as it functions only as a passive bus terminator.
Q6: Is the installation tool-free?
A6: Yes, it can be installed and removed without tools using a DIN rail mounting system.
Q7: Can the module be reused in a new setup?
A7: Yes, if undamaged, it can be reused in another TM5 configuration.
Q8: What material is the housing made من?
A8: The housing is made من industrial-grade plastic suitable for standard cabinet environments.
Q9: What is the IP rating من this module?
A9: It has an IP20 rating, meaning it’s protected from solid objects greater than 12mm but not from liquids.
Q10: Does TM5ACLPR1 provide surge protection?
A10: No, this module does not include surge protection—it only serves as a physical termination.
