Product Overview
The Schneider Electric ATV630D90N4 is a high-performance variable speed drive in the Altivar Process ATV630 series, engineered for fluid and process control applications requiring reliable operation and energy efficiency. It supports up to 90 kW (125 HP) motors and operates on a 3-phase 380–480 V AC power supply.
Ideal for pumps, fans, and compressors in industries such as water treatment, HVAC, and oil & gas, the ATV630D90N4 منfers advanced motor control, built-in communication interfaces, and diagnostic tools that optimize performance and uptime.
Key Features
-
الدعمs 90 kW (125 HP) asynchronous and synchronous motors
-
Operates on 3-phase 380–480 V AC input
-
Advanced motor control: V/f and vector control
-
Built-in Modbus TCP, Ethernet/IP, and CANopen communication
-
Integrated EMC filtering (C3)
-
IP21/NEMA Type 1 enclosure for indoor mounting
-
Conformal coated circuit boards for harsh environments
-
Detachable graphic keypad with navigation dial
-
Built-in energy monitoring and logging tools
-
Robust overload and thermal protection
Technical Specifications
| Item | Specification |
|---|---|
| الطراز Number | ATV630D90N4 |
| Series | Altivar Process ATV630 |
| Power Rating | 90 kW (125 HP) |
| Supply Voltage | 3-phase 380–480 V AC |
| Frequency Range | 50/60 Hz ±5% |
| Output Frequency | 0.1 to 599 Hz |
| Output Current (Nominal) | 170 A |
| Motor Control Type | V/f, Sensorless Vector, Flux Vector |
| Enclosure Rating | IP21 (NEMA Type 1) |
| Communication Protocols | Modbus TCP, Ethernet/IP, CANopen |
| Display Interface | Graphical LCD keypad with dial |
| Overload Capacity | 120% for 60 s, 150% for 60 s |
| EMC Filtering | Integrated الفئة C3 filter |
| Operating Temperature Range | -15°C to +50°C (without derating) |
| Cooling Method | Forced air |
| Mounting Type | Wall-mounted or panel-mounted |
| Dimensions | 290 x 922 x 323mm |
| الوزن | 58.5 kg |
| Certifications | CE, UL, CSA, EAC, RoHS, IEC/EN 61800-5-1 |
Industry Applications
The ATV630D90N4 is designed for use in:
-
Water and wastewater treatment systems
-
HVAC systems in commercial and industrial buildings
-
Oil and gas processing facilities
-
Pulp and paper mills
-
Chemical and petrochemical industries
-
Food and beverage production plants
-
Mining, quarrying, and aggregates handling
Advantages
-
Optimized for Fluid Management: Tailored features for pump and fan control
-
Robust Protection: Smart thermal and overload safeguards extend motor life
-
Easy Integration: Built-in protocols simplify PLC and SCADA connections
-
Energy Efficiency: الدعمs energy savings through smart monitoring
-
User-Friendly: Simple setup via graphical keypad with intuitive controls
-
Environmental Durability: Withstands harsh conditions with conformal coating
-
Global Compliance: Certified for use in global industrial installations
الأسئلة الشائعة (FAQ)
-
What is the motor power supported by ATV630D90N4?
It supports motors up to 90 kW (125 HP). -
Is this drive compatible with Modbus and Ethernet/IP?
Yes, it supports both via built-in communication interfaces. -
Does it include a keypad?
Yes, a graphical LCD keypad with navigation dial is included and detachable. -
Can it be used for fan and pump applications?
Yes, it is optimized for fluid control including fans, pumps, and compressors. -
What kind من environmental protection does it منfer?
It has an IP21/NEMA Type 1 enclosure and conformally coated PCBs. -
Is there overload protection?
Yes, it handles 120% overload for 60 seconds, and 150% for 60 seconds. -
How is it mounted?
It can be wall-mounted or installed in control panels. -
Does the ATV630D90N4 support energy monitoring?
Yes, it has built-in features for tracking and optimizing energy use. -
Is EMC filtering included?
Yes, a الفئة C3 EMC filter is built in. -
Can it be used with synchronous motors?
Yes, it supports both asynchronous and synchronous motors.
Related الطرازs
| الطراز Number | الوصف |
|---|---|
| ATV630D90N4 | 90 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630D75N4 | 75 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630C110N4 | 110 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630D55N4 | 55 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630C13N4 | 132 kW, 380–480 V, IP21, Altivar Process VSD |
| ATV630C22N4 | 220 kW, 380–480 V, IP21, Altivar Process VSD |
Popular Schneider Electric الطرازs
| الطراز Number | الوصف |
|---|---|
| ATV320U75N4B | Altivar Machine 320, 7.5 kW, 380–500 V |
| ATV930C13N4 | Altivar Process 930, 132 kW, advanced performance VSD |
| ATV212HU55N4 | Altivar 212, 55 kW, HVAC-specific drive |
| ATV12H075M2 | Altivar 12, 0.75 kW, compact VSD, single-phase input |
| ATV71HD75N4 | Altivar 71, 75 kW, high-performance drive |
