The Ovation 5A26304G02 Power Panel Module is a critical component in Emerson’s Ovation Distributed Control System (DCS), designed to manage, distribute, and regulate power for control and I/O subsystems. This module acts as the central hub for safe and efficient power handling, ensuring that all connected devices operate under stable and reliable conditions.
Built with advanced electrical design and robust mechanical construction, the 5A26304G02 Power Panel Module is engineered for high reliability in demanding industrial environments. It integrates overcurrent protection, status monitoring, and redundant pathways to minimize downtime. Its modular form factor allows seamless integration into Ovation racks and cabinets, making it a key element for large-scale process automation systems.
مواصفات المنتج
| Parameter | الوصف |
|---|---|
| الطراز Number | Ovation 5A26304G02 Power Panel Module |
| Input Voltage Range | 85 – 264 VAC, 47–63 Hz |
| Output Voltage | 24 VDC regulated |
| Maximum Output Current | 15 A continuous |
| Efficiency | > 85% |
| Protection Features | Overcurrent, surge, thermal shutdown, short-circuit |
| Monitoring Functions | Power status indicators, fault alarms, redundancy support |
| Mounting Type | Rack/chassis mount within Ovation cabinets |
| Cooling Method | Natural convection with support for forced-air cooling |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Dimensions (W × H × D) | 280 × 140 × 70 mm |
| الوزن | 0.14 kg |
Product Applications
The Ovation 5A26304G02 Power Panel Module is designed for industries that require continuous and stable power distribution for automation systems. Typical applications include:
-
Power Generation – Provides stable DC power for turbine controllers, generator protection systems, and excitation modules.
-
Oil & Gas – Powers safety shutdown systems, SCADA وحدةs, and distributed automation controllers.
-
Petrochemical Processing – الدعمs refinery control loops, compressor monitoring, and safety instrumented systems.
-
Water & Wastewater Treatment – Ensures reliable operation من pumps, sensors, and PLC-driven process controls.
-
Industrial Automation – Delivers regulated DC power to HMIs, PLCs, and communication equipment within DCS أوفايشن.
Product Advantages
-
High Reliability: Built with industrial-grade components for continuous operation in critical facilities.
-
Integrated Protection: Includes multiple safeguards against electrical faults, ensuring equipment safety.
-
Redundancy Capability: الدعمs parallel operation to maintain uptime in the event من a module failure.
-
Ease من Maintenance: Hot-swappable design enables replacement without interrupting plant operations.
-
Compact Modular Design: Optimized for space-efficient integration into Ovation racks.
-
System Compatibility: Seamlessly interfaces with other DCS أوفايشن hardware and I/O subsystems.
FAQ
-
What input voltage range does the 5A26304G02 support?
It supports a wide AC input range from 85 to 264 VAC, making it adaptable to unstable or fluctuating grids. -
What DC output does this power panel provide?
The module delivers a regulated 24 VDC output to ensure stable operation من connected Ovation devices. -
What is the maximum current capacity من the وحدة?
The module can supply up to 15 A من continuous current for high-demand system applications. -
Does the module include redundancy support?
Yes, it is designed to work in parallel with additional وحدةs for load sharing and fault-tolerant redundancy. -
What types من protection are built into the module?
It includes overcurrent, surge suppression, short-circuit, and thermal protection features. -
Can the module provide fault monitoring signals?
Yes, it is equipped with status indicators and fault alarms for integration into monitoring systems. -
How stable is the DC output under load variations?
The module maintains tight regulation, ensuring minimal fluctuation even under sudden load changes. -
Is the module hot-swappable?
Yes, it supports live replacement, allowing maintenance without system shutdown. -
How does the cooling mechanism work?
It primarily uses natural convection cooling, with provisions for forced-air cooling in dense enclosures. -
Which Ovation subsystems are typically powered by this module?
It powers I/O racks, control processors, communication gateways, and auxiliary DCS أوفايشن hardware.
