مقدمة المنتج
The Ovation 1X00161H01 Fast Ethernet Network Card is a high-performance communication interface designed to integrate seamlessly with Emerson Ovation Distributed Control Systems (DCS). It provides reliable 10/100 Mbps Ethernet connectivity between Ovation controllers, operator workstations, and SCADA servers. Built for demanding industrial environments, the 1X00161H01 supports deterministic data exchange, low-latency communication, and advanced diagnostic features. Its rugged construction and extended environmental tolerances make it ideal for mission-critical process automation in power generation, water treatment, petrochemical plants, and other heavy industries.
مواصفات المنتج
| Parameter | Details |
|---|---|
| الطراز Number | 1X00161H01 |
| Product Type | Fast Ethernet Network Interface Card |
| Data Rate | 10/100 Mbps full/half duplex |
| Bus Interface | High-speed Ovation system backplane connector |
| Communication Protocols | TCP/IP, UDP, SNMP for management |
| MAC Address | Factory-programmed, globally unique |
| Frame Buffer Memory | 256 KB |
| Power Requirement | 5 VDC @ 0.5 A (from Ovation chassis) |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Diagnostic Features | Link/Activity LEDs, built-in self-test |
| Cooling Method | Passive convection |
| Dimensions (L × W × H) | 180 × 20 × 100 mm |
| الوزن | 0.5 kg |
| Compliance | CE, FCC Class A, UL, RoHS |
Applications
-
Power Generation Plants – Provides high-speed networking between Ovation controllers, engineering workstations, and SCADA nodes.
-
Water & Wastewater Facilities – الدعمs reliable supervisory control and real-time monitoring for distributed pumping stations.
-
Petrochemical and Refining Plants – Ensures secure, low-latency data transfer in hazardous industrial environments.
-
Industrial Automation – Enables deterministic Ethernet communication for PLCs, remote I/O, and SCADA servers.
-
Transportation Infrastructure – Integrates tunnel ventilation systems, rail automation, and traffic monitoring networks.
-
Data Acquisition Systems – Offers fast connectivity for centralized logging and analysis من field measurements.
Advantages
-
Industrial Durability – Wide temperature tolerance and vibration-resistant design for harsh plant conditions.
-
High Throughput – الدعمs full-duplex 100 Mbps data rates with low jitter and minimal packet loss.
-
Simple Integration – Fully compatible with DCS أوفايشن backplane slots and drivers for quick installation.
-
Advanced Diagnostics – LED indicators and built-in self-test functions simplify troubleshooting and maintenance.
-
Secure Management – الدعمs SNMP and TCP/IP protocols for reliable remote monitoring and configuration.
-
Low Maintenance – Passive cooling and solid-state components reduce downtime and service costs.
FAQ
-
What Ethernet speeds are supported by the 1X00161H01?
It supports both 10 Mbps and 100 Mbps Ethernet in full or half-duplex modes. -
Does this card support standard TCP/IP communication?
Yes, it is fully compatible with TCP/IP and UDP protocols for integration with standard Ethernet networks. -
Is VLAN tagging supported on this module?
VLAN support is provided through managed network configurations on connected switches. -
How does the card indicate link or activity status?
Integrated LEDs provide real-time link, speed, and activity indications for quick diagnostics. -
What is the typical latency من data transmission?
The card منfers microsecond-level latency, ensuring deterministic communication for control applications. -
Can the card be used in redundant network setups?
Yes, it supports network redundancy when deployed with Ovation or other industrial managed switches. -
What backplane interface is required?
It plugs directly into the DCS أوفايشن system backplane using the high-speed proprietary connector. -
Does it require external power?
No, it is powered entirely from the Ovation chassis 5 VDC supply. -
Are there built-in diagnostics for fault detection?
Yes, self-test routines and SNMP monitoring provide early warning من communication issues. -
Is the card suitable for extreme environments?
Absolutely. It operates reliably between –40 °C and +70 °C with 5–95% non-condensing humidity.
Related الطرازs (Same Series)
| الطراز Number | Key Feature |
|---|---|
| 1X00133H01 | Fast Ethernet DAS NIC for high-speed data acquisition |
| 1X00160H01 | Gigabit Ethernet Network Card for higher bandwidth needs |
| 1X00162H01 | Dual-port Fast Ethernet NIC for redundant connections |
| 1X00163H01 | Managed Ethernet Switch Module for DCS أوفايشن networks |
| 1X00164H01 | Fiber-optic Ethernet NIC for long-distance communication |
| 1X00165H01 | High-performance network card with enhanced security features |
Popular Ovation الطرازs
| الطراز Number | Primary Application |
|---|---|
| 1X00097H01 | 24 VDC Power Supply for Ovation controllers and I/O modules |
| 1X00095H01 | Industrial Ethernet Switch for robust plant network backbones |
| 1X00106H01 | Ovation controller module for distributed process control |
| 5A26457G01 | Relay output base for robust signal switching |
| 1X00010G01 | Analog input module for precision process measurement |
| 1X00011G01 | Digital input module for real-time signal monitoring |
