مقدمة المنتج
The Ovation 1C31164G01 RTD Input Module is engineered to provide precise and reliable temperature measurements by accepting signals from Resistance Temperature Detectors (RTDs). This module is an integral component in the Ovation control system, designed specifically to interface with RTDs for process monitoring and control applications.
With its advanced signal conditioning capabilities, the 1C31164G01 ensures accurate temperature data collection by compensating for lead wire resistance and electrical noise. It supports multiple RTD types and wiring configurations, making it flexible for diverse industrial environments such as power plants, chemical processing, and manufacturing facilities.
Built for durability and ease من integration, this module supports stable operation over a wide temperature range, ensuring consistent performance in harsh conditions. Its compact form factor and DIN rail mounting compatibility enable straightforward installation in existing control panels.
مواصفات المنتج
| Parameter | Specification |
|---|---|
| الطراز Number | 1C31164G01 |
| Module Type | RTD Input Module |
| الدعمed RTD Types | Pt100, Pt1000, Ni120, Ni100, others |
| Number من Channels | 8 channels |
| Input Configuration | 2-wire, 3-wire, 4-wire RTDs supported |
| Input Range | -200°C to +850°C |
| Accuracy | ±0.1°C (typical) |
| Sampling Rate | 1 sample per second per channel |
| Input Impedance | >10 MΩ |
| Signal الحالةing | Lead wire resistance compensation |
| Noise Immوحدةy | High (EMI/RFI resistant design) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Power Supply | Powered by Ovation backplane |
| Dimensions (WxHxD) | 120 x 90 x 60 mm |
| الوزن | 0.5 kg |
| Mounting | DIN rail compatible |
| Certifications | CE, UL certified |
Product Applications
The Ovation 1C31164G01 RTD Input Module finds its use across many industrial sectors where accurate temperature monitoring is critical:
-
Power Generation: Monitoring boiler, turbine, and generator temperatures for safe and efficient operation.
-
Chemical Processing: Precise temperature control during chemical reactions and storage.
-
Oil and Gas: Measuring temperatures in pipelines, refineries, and processing plants.
-
Water and Wastewater Treatment: Tracking temperature for treatment process optimization.
-
Manufacturing: Ensuring thermal consistency in production lines, ovens, and curing processes.
-
HVAC Systems: Monitoring temperature for building climate control and energy management.
-
Food and Beverage Industry: Temperature control in processing and storage to ensure quality and safety.
Product Advantages
-
Wide RTD Compatibility: الدعمs multiple RTD types and wiring configurations for versatile application.
-
High Measurement Accuracy: Provides ±0.1°C typical accuracy to ensure precise temperature data.
-
Lead Wire Compensation: Automatically compensates for lead wire resistance, reducing measurement errors.
-
Noise Resistant Design: Built to resist electrical interference ensuring stable and reliable data.
-
Compact and Robust: Small footprint with durable housing for harsh industrial environments.
-
Easy Integration: Fits into standard Ovation control systems and DIN rail mounting for hassle-free installation.
-
Stable Performance: Operates reliably across a broad temperature range with high repeatability.
-
Certified for Safety: CE and UL certifications guarantee compliance with industry standards.
الأسئلة الشائعة (FAQ)
-
Q: What types من RTDs are supported by the 1C31164G01?
A: It supports Pt100, Pt1000, Ni120, Ni100, and several other RTD types. -
Q: How many channels does the module have?
A: The module provides 8 RTD input channels. -
Q: Can this module compensate for lead wire resistance?
A: Yes, it supports 2-wire, 3-wire, and 4-wire configurations with lead wire resistance compensation. -
Q: What is the measurement accuracy?
A: Typical accuracy is ±0.1°C over the operating temperature range. -
Q: What is the operating temperature range من the module?
A: It operates between -20°C and +70°C. -
Q: How is the module powered?
A: The module receives power from the Ovation system backplane. -
Q: Is the module suitable for noisy industrial environments?
A: Yes, it is designed with high noise immوحدةy against EMI and RFI. -
Q: What is the physical size من the module?
A: Dimensions are 120 x 90 x 60 mm. -
Q: Does the module require calibration?
A: Periodic calibration is recommended to maintain accuracy but it comes factory calibrated. -
Q: Is the module certified for safety and compliance?
A: Yes, it holds CE and UL certifications.
Related الطرازs and Variants
| الطراز Number | الوصف | Key Feature |
|---|---|---|
| 1C31164G02 | RTD Input Module, 16 Channels | الدعمs more input channels |
| 1C31165G01 | Thermocouple Input Module | For thermocouple temperature sensors |
| 1C31166G01 | Analog Input Module | General analog input signals |
| 1C31167G01 | Digital Input Module | Discrete digital input signals |
| 1C31168G01 | RTD Module with Extended Temp Range | Operates -40°C to +85°C |
| 1C31169G01 | RTD Module with Wireless Interface | Enables remote monitoring |
Popular Ovation العلامة التجارية الطرازs
| الطراز Number | الوصف | Application Focus |
|---|---|---|
| 1C31110G01 | Analog Input Module | Versatile analog measurement |
| 1C31120G01 | Analog Output Module | Signal control output |
| 1C31130G01 | Relay Output Module | Switching control devices |
| 1C31200G01 | Communication Module | System network connectivity |
| 1C31300G01 | Processor Module | Central control processing |
| 1C31150G01 | Pulse Accumulator Module | Pulse signal counting |
