مقدمة المنتج
The Ovation 1C31113G02 Analog Input Module is a core component من Emerson’s Ovation™ Distributed Control System (DCS), providing high-accuracy analog input functionality for process industries. Designed to handle a variety من analog signal types, this module ensures precise data acquisition from field devices such as transmitters, sensors, and other instrumentation.
Known for its stability, noise immوحدةy, and fast processing capabilities, the 1C31113G02 is trusted in critical process environments where accuracy and reliability are non-negotiable. The module منfers seamless integration into Ovation control architecture, supporting high-speed communication with controllers and operator workstations.
With its modular and hot-swappable design, this analog input module simplifies maintenance and system expansion, making it suitable for modern and legacy Ovation systems alike.
مواصفات المنتج
| Parameter | Specification |
|---|---|
| الطراز Number | 1C31113G02 |
| Product Type | Analog Input Module (AI) |
| Number من Channels | 8 channels per module |
| Input Signal Range | 4-20 mA, 0-10 V DC, ±10 V DC, thermocouple, RTD |
| Input Resolution | 16-bit ADC resolution |
| Isolation | 1500 V AC channel-to-bus and channel-to-channel |
| Update Rate | Configurable, typically <10 ms per channel |
| Accuracy | ±0.1% من full scale |
| Input Impedance | > 1 MΩ |
| Power Supply Voltage | 24 V DC nominal (supplied from rack) |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5% to 95% non-condensing |
| Dimensions (WxHxD) | 45 x 120 x 200 mm |
| الوزن | 0.28 kg |
| Mounting | Rack-mounted, hot-swappable |
| Certifications | CE, UL, CSA, FM Class I Div 2, ATEX |
Applications
The 1C31113G02 Analog Input Module is used in a wide range من industries where reliable process monitoring is critical:
-
Power Generation: Boiler and turbine monitoring, emissions control, balance-من-plant instrumentation.
-
Oil & Gas: Process variable monitoring in upstream, midstream, and refining applications.
-
Chemical & Petrochemical: Reactor temperature, pressure, and flow measurement in continuous and batch processes.
-
Water & Wastewater: Flow, level, and quality monitoring in water treatment plants.
-
Pharmaceutical: Compliant process monitoring for GMP/validation purposes.
-
Metals & Mining: Furnace control, pressure and flow monitoring in heavy industrial applications.
Advantages
-
High Accuracy: 16-bit resolution ensures precise analog data acquisition for critical process control.
-
Flexible Signal الدعم: Accepts current, voltage, RTD, and thermocouple inputs — reducing hardware variation across applications.
-
Hot-Swappable Design: Modules can be replaced without shutting down the system, improving maintainability.
-
High Isolation: Protects against ground loops and improves signal integrity.
-
Fast Update Rates: Enables accurate control and timely process response.
-
Ovation Integration: Seamless communication with Ovation controllers and workstations.
-
Noise Immوحدةy: Designed for industrial environments with excellent EMI/RFI performance.
-
Space-Efficient: Compact module fits neatly into Ovation racks.
-
Certified for Hazardous Areas: Meets global standards for use in Class I Div 2 and ATEX zones.
-
Long Lifecycle: Backed by Emerson’s commitment to long-term DCS support and spare parts availability.
الأسئلة الشائعة (FAQ)
-
How many analog input channels does the 1C31113G02 module support?
It supports 8 independent analog input channels per module. -
What types من signals can this module handle?
It accepts 4-20 mA, 0-10 V DC, ±10 V DC, RTDs, and thermocouples. -
What is the resolution من the analog input?
The module provides 16-bit resolution for precise measurements. -
Does the module provide isolation?
Yes, the channels are isolated to 1500 V AC to ensure signal integrity. -
Is the module hot-swappable?
Yes, it can be removed and replaced without shutting down the system. -
What is the update rate من this module?
The update rate is configurable, with typical performance under 10 ms per channel. -
What is the operating temperature range?
The operating temperature range is 0°C to +60°C. -
Is it compatible with existing Ovation systems?
Yes, the 1C31113G02 integrates seamlessly with both legacy and modern Ovation systems. -
Is the module certified for hazardous areas?
Yes, it is certified for Class I Div 2 and ATEX hazardous area use. -
How is the module mounted?
It is rack-mounted in standard Ovation chassis, and supports hot-swap installation.
Recommended Related الطرازs (Same Series or Similar Function)
| الطراز Number | Function / الوصف | Dimensions (WxHxD) mm | الوزن (kg) | Notes |
|---|---|---|---|---|
| 1C31113G01 | Analog Input Module (older version) | 140 x 180 x 100 | 1.6 | Predecessor to 1C31113G02 |
| 1C31125G02 | Analog Output Module | 140 x 180 x 100 | 1.6 | For analog output signals (4-20 mA) |
| 1C31116G02 | Digital Input Module | 140 x 180 x 100 | 1.6 | Discrete digital inputs |
| 1C31129G03 | Digital Output Module | 140 x 180 x 100 | 1.6 | Discrete digital outputs |
| 1C31166G01 | Universal I/O Module | 140 x 180 x 100 | 1.6 | الدعمs both AI and DI functions |
| 1C31234G01 | High-Density Analog Input Module | 140 x 180 x 100 | 1.6 | Higher channel count AI module |
Popular Emerson/Ovation الطرازs (أخرى Product Lines)
| الطراز Number | Product Type | Dimensions (WxHxD) mm | الوزن (kg) | الوصف |
|---|---|---|---|---|
| OCX8800 | Oxygen Analyzer | 305 x 100 x 75 | 2.0 | Combustion process analyzer |
| Ovation OCC100 | Compact Controller | 300 x 200 x 120 | 4.5 | Compact version من Ovation controller |
| 1C31125G01 | Analog Output Module | 140 x 180 x 100 | 1.6 | 4-20 mA analog outputs |
| DeltaV CHARMs IO | Flexible I/O Module | Various | – | Used in DeltaV DCS systems |
| AMS Trex Communicator | Portable Field Communicator | Handheld | 1.2 | For field device configuration |
| Ovation SCADA | SCADA and HMI sمنtware | Sمنtware-only | – | Supervisory control for remote assets |
