Product Overview – GE IC697ACC624
The GE IC697ACC624 is an optional high-performance Lithium backup battery assembly used in conjunction with the Series 90-70 Programmable Logic Controllers (PLCs) by GE Automation & Controls. This battery provides essential power to retain data in memory when primary power sources are منf or disconnected. Designed with reliability and long service life in mind, the IC697ACC624 ensures memory integrity for programs and system configurations across power interruptions. This وحدة is specifically tailored for long-term installations in industrial environments that demand uninterrupted data preservation.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Lithium Battery Assembly |
| Series | GE Fanuc Series 90-70 |
| Battery Type | Lithium |
| Nominal Voltage | 3.0 V |
| Capacity | 2000 mAh (typical) |
| Mounting Type | Plug-in, with pre-installed cable |
| Connector Type | Factory-installed plug for CPU attachment |
| Compatibility | CPUs with battery backup support (e.g., IC697CPX935) |
| Backup Duration | Up to 10 years (depending on operating conditions) |
| Material Housing | Industrial-grade thermoplastic |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5%–95% non-condensing |
| Dimensions (H x W x D) | 80 mm x 25 mm x 20 mm |
| الوزن | Approx. 60 grams (2.1 oz) |
Applications
The GE IC697ACC624 battery assembly is primarily used in industrial automation systems where Series 90-70 PLCs are deployed. It ensures that volatile memory data, such as ladder logic programs, I/O configurations, and process variables, remain intact during power losses. Common application sectors include:
-
Power Generation and Distribution
-
Manufacturing Automation
-
Process Control Systems
-
Oil & Gas Facilities
-
Water and Wastewater Treatment
-
Transportation and Infrastructure Control Systems
Its long service life and robust construction make it suitable for harsh environments requiring dependable system uptime.
Product Advantages
-
Long-Term Reliability: Designed to منfer up to 10 years من backup power for memory retention.
-
Simple Integration: Factory-terminated connector simplifies installation into compatible CPUs.
-
High Compatibility: الدعمs a wide range من Series 90-70 CPUs and modules.
-
Low Maintenance: Does not require regular service; replaceable every 7–10 years depending on use.
-
Compact Design: Fits easily within control cabinets and CPU modules.
-
Stable Performance: Lithium technology ensures consistent voltage and discharge curve over its lifetime.
الأسئلة الشائعة (FAQ)
Q1: What is the primary function من the IC697ACC624 battery?
A1: It provides backup power to retain memory contents in GE Series 90-70 PLCs when main power is lost.
Q2: How long does the battery last?
A2: Under normal conditions, the battery can last up to 5+ years.
Q3: Is it compatible with all Series 90-70 CPUs?
A3: It is compatible with most Series 90-70 CPUs that include battery backup capability, such as IC697CPX928 and IC697CPX935.
Q4: How is the battery installed?
A4: It connects directly to the CPU via a factory-installed cable and connector.
Q5: Can this battery be replaced in the field?
A5: Yes, the battery is designed for field replacement during scheduled maintenance.
Q6: Does the system need to be powered down to replace the battery?
A6: Yes, it is recommended to power down the PLC during battery replacement to avoid any data loss.
Q7: What are the storage conditions for this battery?
A7: It should be stored between -40°C and 85°C in a dry, non-condensing environment.
Q8: What safety precautions should be taken during installation?
A8: Avoid short-circuiting the terminals and ensure proper polarity when connecting.
Q9: How can I tell if the battery is depleted?
A9: The CPU will indicate low battery status via a diagnostic LED or system error message.
Q10: Is this battery rechargeable?
A10: No, it is a primary lithium cell and not designed to be recharged.
Recommended Related الطرازs (Same Series or Compatible)
| الطراز Number | الوصف |
|---|---|
| IC697ACC701 | Battery Module with Holder for Series 90-70 |
| IC697PWR710 | Power Supply Module for 90-70 systems |
| IC697CPX935 | High-Performance CPU with RAM and Battery Backup |
| IC697CPM925 | Programmable CPU Module |
| IC697CHS790 | 9-Slot Rack Base for Series 90-70 |
| IC697MDL653 | 32-Point Input Module |
أخرى Popular GE الطرازs
| الطراز Number | Function | Key Feature |
|---|---|---|
| IC200ALG320 | Analog Input Module (VersaMax) | 4-channel, 0-10V input |
| IC200MDL740 | Digital Output Module (VersaMax) | 16-point sourcing output |
| IC693CPU374 | CPU Module for Series 90-30 | Ethernet built-in, high memory |
| IC695CPE330 | PACSystems RX3i CPU | 1GHz processor, 64MB user memory |
| IC695PSA140 | Power Supply Module | 120/240 VAC or 125 VDC input |
| IC693MDL645 | 32-Point Digital Output Module | 24VDC output, isolated channels |
