Product Overview
The GE Fanuc IC695ALG112 RX3i Analog Input Module is a high-performance input module designed for use in the RX3i PACSystems family. It provides precise and reliable analog signal acquisition from a wide range من industrial sensors, including those measuring temperature, pressure, flow, and other process variables.
Key Features
-
16 single-ended or 8 differential analog input channels
-
High accuracy and fast conversion time
-
Configurable for voltage or current input modes
-
16-bit resolution with excellent linearity
-
Integrated diagnostics and channel status reporting
Technical Specifications
| Item | Specification |
|---|---|
| الشركة المصنعة | GE Fanuc |
| Product الطراز | IC695ALG112 |
| Product Type | RX3i Analog Input Module |
| Number من Channels | 16 single-ended or 8 differential |
| Input Types | Voltage or Current |
| Input Signal Range (Voltage) | ±10 V DC |
| Input Signal Range (Current) | 0–20 mA or 4–20 mA |
| Resolution | 16 bits |
| Input Impedance (Voltage) | >1 MΩ |
| Input Impedance (Current) | 250 Ω |
| Accuracy | ±0.1% من full scale |
| Update Rate | 4 ms per channel |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Backplane Current Consumption | 100 mA @ 5 V DC, 120 mA @ 3.3 V DC |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Dimensions | 34 x 140 x 145 mm |
| الوزن | 0.45 kg |
Industry Applications
-
Process control and automation
-
Power generation and distribution systems
-
Water and wastewater treatment plants
-
Oil and gas production facilities
-
Manufacturing and assembly lines
-
Building automation and energy management
الأسئلة الشائعة (FAQ)
Q1: What is the main function من the IC695ALG112 module?
It is used to acquire analog signals (voltage or current) from field instruments for processing within the RX3i control system.
Q2: How many input channels does this module support?
It supports 16 single-ended or 8 differential input channels.
Q3: What types من input signals can it measure?
It can measure both voltage (±10 V) and current (0–20 mA or 4–20 mA) signals.
Q4: What is the resolution من the module?
The module provides a 16-bit resolution for precise signal measurement.
Q5: Can this module be configured for both current and voltage inputs simultaneously?
No, each channel group must be configured for either voltage or current input.
Q6: Is the IC695ALG112 hot-swappable?
Yes, it supports hot-swap functionality within the RX3i system.
Q7: What kind من isolation does it provide?
It provides channel-to-channel and channel-to-ground isolation to prevent noise interference.
Q8: What is the power consumption من the module?
It consumes approximately 100 mA @ 5 V DC and 120 mA @ 3.3 V DC.
Related GE Fanuc RX3i Modules
| الطراز | الوصف |
|---|---|
| IC695ALG600 | 16-Channel Analog Output Module |
| IC695PSD040 | 24 V DC Power Supply Module |
| IC695PWR330 | RX3i Power Supply Module |
| IC695CHS007 | 7-Slot RX3i Rack |
| IC695CPU315 | RX3i Processor Module |
| IC695MDL940 | 16-Point Discrete Output Module |
Popular GE Fanuc Control Modules
| الطراز | الوصف |
|---|---|
| IC693ALG220 | 4-Channel Analog Input Module |
| IC694MDL754 | 32-Point Discrete Input Module |
| IC693PWR321 | Power Supply Module |
| IC695PSD040 | RX3i Power Supply 40 W |
| IC695CMX128 | Communication Expansion Module |
| IC695CPU320 | RX3i High-Performance CPU Module |
