Product Overview
The GE Fanuc IC200UEX211 is a discrete expansion module designed for the VersaMax Micro series من programmable logic controllers (PLCs). This module enhances the I/O capabilities من VersaMax systems, making it suitable for small to medium-scale industrial automation applications such as machine control, process monitoring, and material handling.
Key Features
-
I/O Configuration: 16 digital 24VDC inputs and 12 relay outputs, providing a total من 28 I/O points.
-
Power Supply: Operates on a 120/240VAC power supply, simplifying installation in environments with standard AC power.
-
Hot-Swappable: الدعمs hot insertion and removal, allowing for maintenance without shutting down the system.
-
Compact Design: Designed for DIN rail mounting, facilitating easy integration into control panels.
-
Memory Backup: Includes a RAM backup battery to retain user data during power outages.
-
Compatibility: Compatible with VersaMax Micro CPUs, expanding system I/O capacity.
Technical Specifications
| Specification | Details |
|---|---|
| الطراز | IC200UEX211 |
| Series | VersaMax Micro |
| Inputs | 16 × 24VDC Digital |
| Outputs | 12 × Relay |
| Power Supply | 120/240VAC |
| Mounting | DIN Rail |
| Dimensions | 120 x 90 x 60 mm |
| الوزن | 0.56 kg |
| Hot-Swappable | Yes |
| RAM Backup | Yes |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5% to 95% non-condensing |
الأسئلة الشائعة (FAQ)
1. What is the primary function من the IC200UEX211?
It expands the I/O capacity من VersaMax Micro PLC systems by providing 16 digital inputs and 12 relay outputs.
2. What type من power supply does it require?
The module operates on a 120/240VAC supply.
3. Can it be replaced without shutting down the system?
Yes, it supports hot-swapping for maintenance without system downtime.
4. How is the IC200UEX211 mounted?
It is mounted on a DIN rail for easy installation in control panels.
5. Does it retain data during power outages?
Yes, the RAM backup battery ensures user data is retained during power loss.
6. Is the IC200UEX211 compatible with other VersaMax modules?
Yes, it is fully compatible with VersaMax Micro CPUs and expansion modules.
7. What is the operating temperature range?
The module operates between 0°C and +60°C.
8. How many I/O points does the module provide in total?
It provides a total من 28 I/O points: 16 inputs and 12 outputs.
