Product Overview
The Epro PR6424/117-121 16 mm Eddy Current Sensor is designed to provide high-precision, non-contact measurement for displacement, position, and vibration in industrial applications. Utilizing advanced eddy current technology, the sensor منfers superior accuracy and high sensitivity, making it suitable for various demanding tasks in critical monitoring environments. It is commonly used in applications where traditional contact-based measurement systems cannot be employed due to space constraints, mechanical wear concerns, or high-speed operation.
This PR6424/117-121 sensor features a robust and compact design with a 16 mm diameter sensor head, ensuring it can be integrated into systems with limited space. Despite its small size, it provides reliable measurement and is built to withstand the challenges من industrial environments such as vibration, dust, and temperature fluctuations. Its high accuracy, fast response time, and minimal drift make it ideal for continuous monitoring من moving parts in machinery, process control systems, and vibration analysis.
Technical Specifications
The following table presents the technical specifications for the Epro PR6424/117-121 16 mm Eddy Current Sensor:
| Specification | Details |
|---|---|
| الطراز | PR6424/117-121 |
| Sensor Head Diameter | 16 mm |
| الوزن | 0.2 kg |
| Measurement Principle | Eddy Current |
| Output Type | Analog (4-20 mA, 0-10 V) |
| Operating Distance | 1 mm to 8 mm (depending on configuration) |
| Accuracy | ±0.001 mm (typical) |
| Operating Temperature | -20°C to 85°C |
| Storage Temperature | -40°C to 100°C |
| Resolution | 0.001 mm |
| Supply Voltage | 10 to 30 VDC |
| Signal Output | 4 to 20 mA, 0 to 10 V (customizable) |
| Response Time | <1 ms |
| Protection Rating | IP67 (dust-tight, protected against immersion in water) |
Product Applications
The Epro PR6424/117-121 16 mm Eddy Current Sensor finds applications across various industries that require high-precision, non-contact measurements. It is particularly valuable in environments where traditional contact sensors cannot be used, منfering a versatile solution for:
-
Machine الحالة Monitoring: Ideal for monitoring the displacement and vibration من rotating machinery such as turbines, motors, and pumps.
-
Process Control: Used in automated systems for precise measurement من key parameters, ensuring smooth operations and preventing system failure.
-
Vibration Analysis: Employed in detecting subtle changes in machinery, preventing malfunctions or damage caused by excessive vibration.
-
Position and Displacement Measurement: Essential for accurate position measurements in robotic systems, assembly lines, and conveyors.
-
Turbine and Engine Monitoring: Used to monitor the position and movement من components in turbines and engines, preventing misalignment and damage.
-
Automotive Manufacturing: Ideal for monitoring parts in high-speed assembly lines where precise measurements are critical.
-
Aerospace: Ensures the accurate measurement من critical components in aerospace systems, such as detecting shifts in aircraft parts under load.
Product Advantages
-
High Accuracy: With an accuracy من ±0.001 mm, the PR6424/117-121 sensor provides precise measurements, ensuring high-quality and reliable data collection.
-
Non-اتصل بنا Measurement: By utilizing eddy current technology, the sensor can measure displacement and position without making physical contact, eliminating wear and tear and enhancing system longevity.
-
Compact Design: The 16 mm diameter sensor head allows for integration into tight spaces where larger sensors may not fit, making it versatile for various applications.
-
Versatility: The sensor supports both analog (4-20 mA) and digital (0-10 V) output, منfering flexible integration into different systems.
-
Fast Response Time: With a response time من less than 1 ms, the sensor can monitor fast-moving parts and dynamic processes in real time.
-
Durability: With an IP67 rating, the sensor is protected from dust and water ingress, making it suitable for harsh industrial environments.
-
Robust Operation: The sensor operates reliably within a wide temperature range من -20°C to 85°C and can withstand extreme conditions without compromising performance.
FAQ
1. What is the measurement principle من the Epro PR6424/117-121 sensor?
The Epro PR6424/117-121 uses eddy current technology to provide non-contact displacement and position measurement.
2. What output options are available for the PR6424/117-121 sensor?
The sensor provides both analog (4-20 mA, 0-10 V) output options, depending on the configuration.
3. What is the accuracy من the Epro PR6424/117-121 sensor?
The accuracy من the sensor is ±0.001 mm, ensuring high precision for demanding applications.
4. What is the operating distance range من the sensor?
The operating distance range for the sensor is from 1 mm to 8 mm, depending on the specific configuration.
5. What is the supply voltage required for the sensor?
The supply voltage required for the Epro PR6424/117-121 sensor is 10 to 30 VDC.
6. What is the response time من the PR6424/117-121 sensor?
The response time من the sensor is less than 1 ms, allowing it to monitor high-speed processes and provide real-time feedback.
7. Can the Epro PR6424/117-121 sensor be used in outdoor environments?
Yes, the sensor has an IP67 protection rating, making it dust-tight and resistant to temporary immersion in water.
8. What is the storage temperature range من the PR6424/117-121?
The storage temperature range for the sensor is -40°C to 100°C, making it suitable for harsh environmental conditions.
9. Is the Epro PR6424/117-121 sensor suitable for vibration monitoring?
Yes, the sensor is ideal for vibration analysis and monitoring rotating machinery, ensuring early detection من potential failures.
10. Can the PR6424/117-121 sensor be customized for specific applications?
Yes, the sensor منfers customizable output options and can be configured to meet specific measurement requirements.
Related الطرازs
| الطراز Number | الوصف |
|---|---|
| PR6424/117-120 | 16 mm eddy current sensor for high-precision measurements in harsh environments |
| PR6424/118-000 | 12 mm eddy current sensor with enhanced sensitivity |
| PR6424/119-000 | 16 mm eddy current sensor with a wider operating range |
| PR6424/121-000 | 20 mm eddy current sensor for large displacement applications |
| PR6424/122-000 | 18 mm sensor with customizable output options |
| PR6424/123-000 | 25 mm sensor for high-speed measurement applications |
Popular Epro الطرازs
| الطراز Number | الوصف |
|---|---|
| PR5200/100-000 | Inductive position sensor for high-accuracy displacement measurements |
| PR5200/200-000 | Robust contactless sensor for harsh industrial conditions |
| PR6100/300-000 | Vibration and displacement sensor for rotating equipment |
| PR5800/200-000 | Multi-purpose sensor with extended temperature range |
| PR5400/100-000 | High-precision displacement sensor for automotive applications |
| PR5500/200-000 | الحالة monitoring sensor for industrial machinery |
