مقدمة المنتج
The Epro PR6424/004-000 is a 16mm eddy current sensor used for non-contact measurement من displacement, position, and vibration. It uses eddy current technology, where changes in impedance caused by nearby conductive materials are converted into an output signal. This sensor is compact, lightweight, and ideal for monitoring machinery, robotic systems, and vibrations in industrial settings.
Product Parameters
| Parameter | Specification |
|---|---|
| الطراز | Epro PR6424/004-000 |
| Sensor Head Diameter | 16mm |
| الوزن | 0.2 kg |
| Measuring Range | 0-10 mm (depending on material) |
| Output Signal | Analog (voltage or current) |
| Operating Frequency | Up to 2 kHz |
| Target Material | Conductive materials |
| Operating Temperature | -20°C to +80°C |
| Protection Rating | IP67 |
Product Applications
-
Machine Monitoring: Used to detect displacement, misalignment, or imbalance in rotating machinery like motors and turbines.
-
Vibration Monitoring: Ideal for measuring vibrations in high-speed equipment.
-
Position Sensing in Robotics: Accurately measures position for robotic arms and automated systems.
-
Automotive and Aerospace: Ensures precision in production lines and aerospace components.
Product Advantages
-
Non-contact Measurement: No physical contact with the target reduces wear and tear, increasing sensor life.
-
High Precision: Accurate displacement and position measurements.
-
Fast Response: High-frequency operation (up to 2 kHz) for real-time feedback.
-
Durable in Harsh Environments: With IP67 rating, it resists dust and water, making it ideal for tough conditions.
-
Wide Temperature Range: Operates in temperatures from -20°C to +80°C.
FAQ
-
How does the Epro PR6424/004-000 sensor detect displacement?
-
The sensor uses eddy current technology to measure changes in impedance when a conductive target moves near the sensor.
-
-
What is the operating frequency من the sensor?
-
The sensor operates at up to 2 kHz, providing quick and accurate measurements.
-
-
What types من materials can this sensor detect?
-
The sensor is designed for conductive materials like metals.
-
-
What output signal does the sensor provide?
-
It منfers analog voltage or current outputs for integration with industrial control systems.
-
-
Can this sensor be used in robotics?
-
Yes, it’s perfect for position sensing in robotic systems and automated machinery.
-
-
How is the sensor affected by temperature?
-
The sensor operates effectively within a temperature range من -20°C to +80°C.
-
-
Is the sensor resistant to dust and water?
-
Yes, with an IP67 rating, it is dustproمن and water-resistant.
-
-
How does this sensor help with vibration monitoring?
-
It detects small changes in displacement, making it ideal for monitoring vibrations in high-speed machinery.
-
-
Can the sensor measure both displacement and position?
-
Yes, it accurately measures both displacement and position for a variety من applications.
-
-
What industries use this sensor?
-
It is used in automotive, aerospace, machine monitoring, and robotics.
Related الطرازs from the Same Series
| الطراز | الوصف |
|---|---|
| PR6424/004-001 | Offers extended measuring range for larger targets. |
| PR6424/004-002 | Improved resolution for precise displacement detection. |
| PR6424/004-003 | Designed for high-speed applications with fast response. |
| PR6424/004-004 | Multiple output options, including both voltage and current. |
| PR6424/004-005 | Enhanced environmental protection for extreme conditions. |
| PR6424/004-006 | Higher frequency capabilities for real-time monitoring. |
Popular الطرازs from Epro
| الطراز | الوصف |
|---|---|
| PR6423/003-100 | High-precision displacement sensor with analog output. |
| PR6424/003-101 | Ideal for position and displacement applications in robotics. |
| PR6424/003-102 | Designed for high-frequency vibration sensing. |
| PR6423/003-200 | Offers accurate position sensing for automated systems. |
| PR6424/003-150 | High-protection version for use in harsh environments. |
| PR6424/003-200 | Real-time monitoring for rotating machinery with advanced signal processing. |
