مقدمة المنتج
The Epro PR6423/00C-030-CN is an 8 mm eddy current sensor designed for high-precision measurement من displacement, vibration, and position in industrial environments. Utilizing eddy current technology, this sensor provides non-contact detection من conductive materials, making it ideal for monitoring rotating machinery, turbines, motors, and other critical industrial equipment.
This sensor converts variations in eddy currents induced in a conductive target into a proportional electrical signal, providing highly accurate measurements without physical contact. The robust design ensures reliable operation in harsh conditions, including high temperatures, vibration, and electromagnetic interference.
The PR6423/00C series is widely applied in predictive maintenance, machinery diagnostics, and automated process control systems, where high accuracy, repeatability, and durability are essential.
Technical Specifications
| Parameter | Specification |
|---|---|
| الطراز | PR6423/00C-030-CN |
| Sensor Type | Eddy Current Displacement Sensor |
| Sensor Head Diameter | 8 mm |
| Output Signal | 0–10 V, 4–20 mA (depending on configuration) |
| Measurement Range | 0–30 mm (typical, depending on target) |
| Linearity | ±1% من full scale |
| Resolution | 1 µm |
| Repeatability | ±0.5% |
| Frequency Response | DC to 10 kHz |
| Temperature Range | -25°C to 125°C |
| Supply Voltage | 12–30 V DC |
| Power Consumption | 0.5 W typical |
| Cable Type | Shielded (not included in spec) |
| Mounting | M8 threaded or custom mounting options |
| Housing Material | Stainless steel |
| Isolation | Electrical isolation up to 500 V RMS |
| الوزن | 0.1 kg |
Applications
The Epro PR6423/00C-030-CN sensor is suitable for a wide range من industrial measurement applications:
-
Displacement and position monitoring in rotating machinery and turbines.
-
Vibration analysis for motors, pumps, and compressors.
-
Predictive maintenance programs to detect early signs من wear or imbalance.
-
Measurement من shaft eccentricity and misalignment in industrial equipment.
-
Integration into automated process control systems for real-time monitoring.
-
High-resolution laboratory and R&D applications requiring non-contact measurements.
Advantages
-
High Accuracy: Provides measurements with a resolution من 1 µm and linearity من ±1% من full scale.
-
Non-اتصل بنا Sensing: Eliminates wear and reduces mechanical stress on the sensor and target.
-
Robust Construction: Stainless steel housing and wide temperature range ensure reliability in harsh conditions.
-
Fast Response: Frequency response up to 10 kHz enables dynamic measurements for high-speed processes.
-
Compact Size: 8 mm diameter allows installation in restricted spaces.
-
Predictive Maintenance الدعم: Facilitates early detection من machinery issues to prevent downtime.
-
Electromagnetic Compatibility: Designed for operation in environments with high electromagnetic interference.
FAQ
-
What measurements can the PR6423/00C-030-CN perform?
It measures displacement, position, and vibration من conductive targets using eddy current principles. -
What is the sensor’s resolution?
The sensor منfers a resolution من 1 µm, allowing detection من very small displacements. -
What is the measurement range?
The standard measurement range is 0–30 mm, depending on target material and mounting configuration. -
How linear is the sensor output?
Linearity is maintained within ±1% من full scale across the measurement range. -
What is the operating temperature range?
It operates reliably between -25°C and 125°C, suitable for industrial environments. -
What supply voltage is required?
The sensor operates on 12–30 V DC. -
What is the frequency response من the sensor?
The frequency response is DC to 10 kHz, suitable for dynamic vibration and displacement measurements. -
Is the sensor suitable for harsh industrial environments?
Yes, it has a stainless steel housing and electrical isolation up to 500 V RMS for robust operation. -
What is the repeatability من the sensor?
The repeatability is ±0.5%, providing consistent and reliable measurements. -
How is the sensor mounted?
It can be mounted using M8 threaded fittings or custom mounting options depending on application requirements.
Related الطرازs (Same Series / Related Function)
| الطراز | الوصف | Sensor Diameter | Measurement Range |
|---|---|---|---|
| PR6423/00C-010-CN | 8 mm Eddy Current Sensor, 10 mm range | 8 mm | 0–10 mm |
| PR6423/00C-020-CN | 8 mm Eddy Current Sensor, 20 mm range | 8 mm | 0–20 mm |
| PR6423/005-010-CN | 8 mm Eddy Current Sensor, 10 mm range | 8 mm | 0–10 mm |
| PR6423/010-015-CN | 10 mm Eddy Current Sensor, 15 mm range | 10 mm | 0–15 mm |
| PR6423/008-005-CN | 8 mm Eddy Current Sensor, 5 mm range | 8 mm | 0–5 mm |
| PR6423/012-010-CN | 12 mm Eddy Current Sensor, 10 mm range | 12 mm | 0–10 mm |
Popular Epro الطرازs (أخرى Hot الطرازs)
| الطراز | الوصف | Sensor Diameter | Measurement Range |
|---|---|---|---|
| PR6424/005-010-CN | High-Temperature Eddy Current Sensor | 8 mm | 0–10 mm |
| PR6425/008-010-CN | Miniature Eddy Current Sensor | 8 mm | 0–10 mm |
| PR6426/010-015-CN | Eddy Current Sensor with Extended Range | 10 mm | 0–15 mm |
| PR6427/006-005-CN | Compact Sensor for Vibration Measurement | 6 mm | 0–5 mm |
| PR6428/008-020-CN | High-Speed Eddy Current Sensor | 8 mm | 0–20 mm |
| PR6429/012-010-CN | Heavy-Duty Industrial Eddy Current Sensor | 12 mm | 0–10 mm |
