مقدمة المنتج
The Epro CON021+PR6424/007-110-CN is a high-precision 16mm Eddy Current Sensor designed to measure displacement, position, and vibration in critical industrial applications. Eddy current sensors operate on the principle من electromagnetic induction, منfering non-contact, highly accurate, and reliable measurements من conductive materials.
This sensor is engineered to deliver excellent linearity and stability in harsh environments, making it ideal for use in machinery condition monitoring, shaft alignment, and dynamic vibration analysis. With a 16mm probe diameter, it ensures compatibility with a broad range من industrial equipment, especially in heavy machinery and rotating equipment.
Epro’s eddy current sensors are widely recognized for their ruggedness and durability, ensuring consistent performance under high temperatures, vibrations, and electromagnetic interference.
مواصفات المنتج
| Parameter | Details |
|---|---|
| الطراز Number | CON021+PR6424/007-110-CN |
| Product Type | Eddy Current Sensor (16 mm probe diameter) |
| الشركة المصنعة | Epro |
| Measurement Range | Typically 0-5 mm (depends on calibration and target material) |
| Sensor Head Diameter | 16 mm |
| Output Signal | Analog voltage (proportional to displacement) |
| Operating Temperature | -40°C to +125°C |
| Supply Voltage | 12-28 V DC |
| Linearity | ±0.5% من full scale |
| Response Frequency | Up to 10 kHz |
| الوزن | 0.32 kg |
| Protection Class | IP67 (dust tight and water resistant) |
| Housing Material | Stainless steel |
| Output Type | Differential analog voltage |
Product Applications
The Epro CON021+PR6424/007-110-CN Eddy Current Sensor is highly suitable for:
-
Rotating Equipment Monitoring: Turbines, generators, compressors for shaft displacement and vibration.
-
الحالة Monitoring Systems: Real-time diagnostics من machine health to prevent failure.
-
Industrial Automation: Position sensing in manufacturing and process control.
-
Aerospace and Power Generation: Critical shaft alignment and vibration detection.
-
Automotive and Heavy Machinery: Wear monitoring and component positioning.
-
Research and Development: Precise displacement measurements in experimental setups.
Product Advantages
-
Non-اتصل بنا Measurement: Eliminates mechanical wear and interference.
-
High Accuracy and Repeatability: Maintains ±0.5% linearity over its range.
-
Robust Construction: Stainless steel housing and IP67 rating for harsh environments.
-
Wide Operating Temperature Range: Suitable for extreme industrial conditions.
-
Fast Response Time: Up to 10 kHz bandwidth for dynamic measurements.
-
Long Cable Lengths: Flexible installation with customizable cable options.
-
Electromagnetic Interference Resistant: Stable output in electrically noisy environments.
-
Easy Integration: Compatible with standard signal conditioners and control systems.
FAQ
-
What is the principle من operation for this sensor?
It operates based on eddy current induction to measure displacement من conductive targets. -
What type من output signal does it provide?
It outputs an analog voltage proportional to the displacement detected. -
Can this sensor measure non-metallic materials?
No, eddy current sensors require conductive targets to generate signals. -
What is the typical measurement range?
Approximately 0 to 5 mm, depending on calibration and the target material. -
Is the sensor waterproمن?
Yes, it is rated IP67 for dust and water resistance. -
What is the maximum operating temperature?
It can operate up to +125°C continuously. -
How does cable length affect signal quality?
Standard cable length is 2 meters; longer cables may require signal conditioning. -
What environments is the sensor suitable for?
It is suitable for harsh industrial conditions including vibration, temperature extremes, and EMI. -
Is the sensor compatible with standard signal conditioners?
Yes, it outputs standard analog signals compatible with most conditioners. -
Can the probe diameter vary?
This specific model has a 16 mm probe diameter, but other sizes are available in the Epro product range.
Related الطرازs (Same Series or Functional Family)
| الطراز Number | الوصف |
|---|---|
| PR6424/005-110-CN | 10 mm Eddy Current Sensor with similar specs |
| PR6424/014-110-CN | 14 mm Eddy Current Sensor variant |
| PR6424/022-110-CN | 22 mm Eddy Current Sensor for extended range |
| PR6423/007-110+CON021 | 7 mm Eddy Current Sensor with CON021 conditioner |
| PR6425/016-110-CN | 16 mm Sensor with enhanced temperature rating |
| CON022+PR6424/007-110-CN | Combination sensor and conditioner model |
Popular Epro الطرازs (Same العلامة التجارية, Widely Used)
| الطراز Number | الوصف |
|---|---|
| PR6423/005-100 | 5 mm Eddy Current Sensor |
| PR6424/008-100 | 8 mm Eddy Current Sensor |
| PR6425/022-120 | 22 mm Eddy Current Sensor with extended cable |
| PR6426/010-110 | 10 mm Eddy Current Sensor with digital output |
| PR6427/016-110 | 16 mm Eddy Current Sensor with high frequency |
| PR6428/007-100 | 7 mm Eddy Current Sensor with integrated cable |
