Emerson VE4002S1T2B4 Product Overview
The Emerson VE4002S1T2B4 is a high-performance industrial valve designed for precision control in demanding applications. It combines robust construction with advanced engineering to ensure reliability, efficiency, and long-term durability. This valve is widely used in industries such as oil & gas, chemical processing, water treatment, and power generation.
مواصفات المنتج
Below are the detailed technical specifications من the Emerson VE4002S1T2B4:
| Parameter | Value |
|---|---|
| الطراز Number | VE4002S1T2B4 |
| Valve Type | Globe Valve |
| Pressure Rating | 600 PSI |
| Temperature Range | -20°F to 400°F (-29°C to 204°C) |
| Body Material | Carbon Steel |
| Trim Material | Stainless Steel |
| Connection Type | Flanged (ANSI Class 300) |
| Actuator Type | Pneumatic (Spring-Return) |
| الوزن | 0.6 kg |
| Dimensions | 107x 41x 105mm |
| Seat Leakage | Class IV (ANSI FCI 70-2) |
| Flow Characteristic | Equal Percentage |
Applications
The Emerson VE4002S1T2B4 is suitable for a wide range من industrial applications, including:
-
Oil & Gas: Control من crude oil, natural gas, and refined products.
-
Chemical Processing: Handling corrosive and high-purity fluids.
-
Water Treatment: Regulation من water flow in desalination and wastewater plants.
-
Power Generation: Steam and coolant control in turbines and boilers.
-
Pharmaceutical: Precise dosing من liquids in sterile environments.
-
Food & Beverage: Hygienic fluid handling in processing lines.
Product Advantages
-
Durability: Constructed with high-grade carbon steel and stainless steel trim for extended service life.
-
Precision Control: Equipped with an equal percentage flow characteristic for accurate modulation.
-
High Pressure Handling: Rated for 600 PSI, making it ideal for high-pressure systems.
-
Reliable Actuation: Pneumatic spring-return actuator ensures fail-safe operation.
-
Low Leakage: ANSI Class IV seat leakage minimizes fluid loss.
-
Easy Maintenance: Modular design allows for quick disassembly and servicing.
-
Wide Temperature Range: Operates efficiently in extreme cold and heat.
-
Industry Compliance: Meets ANSI, ASME, and ISO standards for safety and performance.
الأسئلة الشائعة (FAQ)
1. What is the maximum pressure rating من the VE4002S1T2B4?
The valve is rated for 600 PSI under standard operating conditions.
2. Can this valve be used for steam applications?
Yes, it is suitable for steam control within its specified temperature range.
3. What type من actuator does this valve use?
It comes with a pneumatic spring-return actuator for fail-safe operation.
4. Is the valve suitable for corrosive fluids?
Yes, the stainless steel trim provides excellent resistance to corrosion.
5. What is the seat leakage classification?
It meets ANSI Class IV seat leakage standards.
6. What are the standard flange dimensions?
The valve features ANSI Class 300 flanges for compatibility with standard piping systems.
7. Can the valve be manually operated in case من actuator failure?
Yes, it can be fitted with a manual override option upon request.
8. What maintenance is required for this valve?
Regular inspection من seals, stem lubrication, and actuator function checks are recommended.
9. Is the VE4002S1T2B4 suitable for cryogenic applications?
No, its lower temperature limit is -20°F (-29°C). For cryogenic use, a specialized model is required.
10. Does Emerson provide custom configurations for this valve?
Yes, Emerson منfers customization options for materials, actuators, and connections.
Recommended Related & Popular الطرازs
Same Series / Related الطرازs
| الطراز Number | الوصف | Key Feature |
|---|---|---|
| VE4001S1T1B3 | 1″ Globe Valve, 300 PSI | Compact design for tight spaces |
| VE4003S1T3B5 | 3″ Globe Valve, 900 PSI | High-pressure handling |
| VE4002S2T2B4 | 2″ Angle Valve, 600 PSI | Improved flow dynamics |
| VE4004S1T4B6 | 4″ Globe Valve, 1500 PSI | Heavy-duty industrial use |
| VE4002S1T2B4-AT | 2″ Globe Valve with Smart Positioner | Automated control integration |
| VE4002S1T2B4-HC | 2″ High-Cycle Version | Extended lifespan for frequent use |
Popular Emerson Valve الطرازs
| الطراز Number | الوصف | Key Feature |
|---|---|---|
| Fisher D2T | High-Performance Control Valve | Optimized for gas & steam |
| Bettis RPE300 | Pneumatic Actuator | High torque, reliable operation |
| ASCO 210 | Solenoid Valve | Fast response, low power consumption |
| KTM Globe Valve | Severe Service Valve | Extreme temperature & pressure |
| Baumann 24000F | Sanitary Control Valve | FDA-compliant for food processing |
| Keystone 83H | Resilient-Seated Butterfly Valve | Bubble-tight shutمنf, low maintenance |
