Product Overview
The Emerson KJ3101X1-BA1 Discrete Output Module is a high-performance output solution designed for use within the Emerson DeltaV™ distributed control system (DCS). Engineered to control discrete field devices such as relays, solenoids, actuators, and indicators, this module provides 16 high-side output channels with fast response and robust diagnostic capabilities. It ensures reliable operation in industrial environments and supports seamless integration into the DeltaV automation platform.
Key Features
-
16 discrete output channels
-
Designed for 24 VDC high-side switching
-
Short-circuit protection for each channel
-
Open/short load diagnostics
-
Hot-swappable under power
-
Channel status LEDs for monitoring and troubleshooting
-
الدعمs fail-safe output configuration
-
Direct integration with DeltaV systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Discrete Output Module |
| Number من Channels | 16 |
| Output Type | 24 VDC high-side sourcing |
| Output Voltage Range | 18–32 VDC |
| Maximum Output Current | 0.5 A per channel |
| Module Power Consumption | < 8 W |
| Diagnostics | Open/short load, over-temperature, short circuit |
| Fail-safe Mode | Configurable output state on fault |
| LED Indicators | Channel-specific status LEDs |
| Hot-Swappable | Yes |
| Dimensions | 200 x 130 x 45 mm |
| الوزن | 0.7 kg |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Mounting | DeltaV I/O carrier |
| Certifications | CE, CSA, UL, RoHS compliant |
Industry Applications
-
Oil & Gas
-
Power Generation
-
Chemical Processing
-
Water and Wastewater Treatment
-
Food and Beverage Manufacturing
-
Pharmaceutical Production
Product Advantages
-
Reliable high-side output switching for various field devices
-
Enhanced fault detection ensures operational safety
-
الدعمs real-time status indication via onboard LEDs
-
Seamless installation in existing DeltaV architecture
-
Designed for rugged industrial conditions
-
Facilitates efficient maintenance with hot-swap support
الأسئلة الشائعة (FAQ)
-
How many output channels are available?
The module supports 16 discrete outputs. -
What voltage is required for output control?
It is designed for 24 VDC output applications. -
Is the module hot-swappable?
Yes, it can be replaced without powering down the system. -
What protection features are included?
Includes short-circuit, open load, and over-temperature diagnostics. -
Are output states configurable on failure?
Yes, fail-safe states can be configured for each channel. -
Can the module be used in safety applications?
It supports diagnostics suitable for safety-related control logic. -
What type من switching is used?
High-side sourcing is employed for each channel. -
Is LED indication available?
Yes, each channel has a dedicated LED for status monitoring. -
What is the max current per output?
Each channel supports up to 0.5 A. -
Which DeltaV systems is this compatible with?
Fully compatible with DeltaV systems using standard I/O carriers.
Related Modules
| الطراز Number | الوصف |
|---|---|
| KJ3001X1-BH1 | Analog Input Module |
| KJ3001X1-CA1 | Discrete Input Module |
| KJ3221X1-BA1 | Analog Output Module |
| KJ3244X1-BA1 | DeviceNet Interface Card |
| KL4503X1-BA1 | PLC Expansion Module |
Popular وحدة إمرسونs
| الطراز Number | الوصف |
|---|---|
| KJ2005X1-MQ2 | DeltaV Controller |
| KJ2231X1-BB1 | Relay Module |
| KJ3003X1-BA1 | Serial Interface Card |
| KJ3005X1-BA1 | Serial Interface Card |
| KJ2001X1-BA1 | Power Module |
