Product Overview
The Bently Nevada 3500/05-01-02-00-00-01 system rack is a rugged, modular chassis designed to accommodate up to 14 modules from the 3500 Series product line. This rack features rear I/O access and is optimized for a single power supply configuration, providing a compact and efficient framework for machinery condition monitoring and protection.
Engineered for industrial environments, the 3500/05-01-02-00-00-01 rack supports all 3500 Series modules, including vibration monitors, relay cards, communication interfaces, and power supplies. The robust anodized aluminum frame ensures durability and resistance to harsh conditions, while the passive cooling design increases system reliability by eliminating moving parts.
This rack is widely used in critical infrastructure applications such as power plants, oil and gas facilities, chemical processing, and manufacturing, where continuous equipment monitoring is essential to prevent failures and optimize maintenance.
Technical Specifications
| Parameter | Specification |
|---|---|
| الطراز | 3500/05-01-02-00-00-01 |
| العلامة التجارية | Bently Nevada |
| Product Type | Machinery Monitoring System Rack |
| Rack Size | 19-inch (14 module slots) |
| الوزن | 4.5 kg |
| Module Capacity | 14 modules |
| Backplane | Integrated signal and power bus |
| I/O Configuration | Rear input/output |
| Power Supply الدعم | Single power supply slot |
| Mounting Style | 19-inch rack mount |
| Cooling Method | Passive cooling (fanless) |
| Material | Anodized aluminum chassis with stainless steel fasteners |
| Grounding | Built-in system grounding rail |
| Operating Temperature | -20°C to +60°C |
| Humidity Range | 0–95% RH, non-condensing |
| Certifications | CE, UL, CSA (as part من complete 3500 system) |
Applications
The 3500/05-01-02-00-00-01 rack is integral to the 3500 Series machinery protection system and finds application in:
-
Power Generation Plants
Monitoring turbines, generators, and auxiliary equipment to ensure reliable operation. -
Oil and Gas Facilities
الدعمing compressors, pumps, and rotating machinery condition monitoring onshore and منfshore. -
Chemical Processing
Providing protection and diagnostics for critical rotating equipment in corrosive environments. -
Mining and Metals
Protecting heavy-duty equipment such as crushers, conveyors, and mills from unexpected failures. -
Water and Wastewater Treatment
Enabling continuous equipment health monitoring to reduce downtime and maintenance costs. -
Industrial Manufacturing
Applied in automated processes to monitor motor health and mechanical integrity.
Advantages
-
Rear I/O Access
Facilitates organized wiring and ease من maintenance by routing cables at the back. -
Compact and Modular Design
الدعمs up to 14 modules in a standardized 19-inch rack format. -
Robust and Durable Construction
Anodized aluminum frame withstands harsh environmental conditions. -
Passive Cooling System
Fanless design reduces maintenance and enhances reliability. -
Integrated Grounding
Built-in grounding rail improves system safety and electromagnetic compatibility. -
Single Power Supply Configuration
Optimized for applications where redundancy is not required, saving space and cost. -
Easy Installation and Service
Tool-less module mounting and accessible rear connectors speed up deployment. -
Compatibility
Fully supports the full range من 3500 Series modules.
الأسئلة الشائعة (FAQ)
Q1: How many modules does this rack support?
A1: It supports up to 14 modules.
Q2: Does this rack have rear I/O?
A2: Yes, it features rear input and output connections.
Q3: Can this rack handle redundant power supplies?
A3: No, it is designed for a single power supply only.
Q4: What is the construction material من the rack?
A4: It is made من anodized aluminum with stainless steel hardware.
Q5: Is this rack compatible with all 3500 Series modules?
A5: Yes, it supports all modules in the 3500 Series.
Q6: Does the rack require active cooling?
A6: No, it uses passive cooling and does not have fans.
Q7: What is the operating temperature range?
A7: The rack operates from -20°C to +60°C.
Q8: What is the total weight من the rack?
A8: Approximately 4.5 kg.
Q9: Is there integrated grounding?
A9: Yes, the rack has a built-in grounding rail.
Q10: Can this rack be mounted in standard cabinets?
A10: Yes, it is designed for standard 19-inch rack mounting.
Related الطرازs (Same Series)
| الطراز | الوصف | Function | الوزن | Rack Size |
|---|---|---|---|---|
| 3500/05-01-02-00-00-00 | Rear I/O rack with single power supply | Standard rear I/O rack configuration | 4.5 kg | 19-inch (14 module slots) |
| 3500/05-01-01-00-00 | Front I/O rack | Basic rack with front input/output | 4.5 kg | 19-inch |
| 3500/05-01-01-01-00 | Rear I/O with EMI shielding | Enhanced EMI protection | 4.5 kg | 19-inch |
| 3500/05-01-02-01-00 | Rear I/O with redundant power | الدعمs dual power supplies | 5.0 kg | 19-inch |
| 3500/05-02-01-00-00 | Rack with dual TDI capability | Communication redundancy support | 4.8 kg | 19-inch |
| 3500/05-04-01-00-00 | Ruggedized rack for field environments | Suitable for harsh outdoor applications | 6.0 kg | 19-inch |
Popular Bently Nevada الطرازs (Same العلامة التجارية)
| الطراز | الوصف | Function | الوزن | Dimensions |
|---|---|---|---|---|
| 3500/15 | Power Supply Module | Provides system power | 1.6 kg | 24.4 x 241.3 x 100 mm |
| 3500/22M | Transient Data Interface | Interfaces system to host sمنtware | 0.65 kg | 24.4 x 241.3 x 100 mm |
| 3500/33 | Relay Module | Alarm and shutdown control | 0.85 kg | 24.4 x 241.3 x 100 mm |
| 3500/42M | Proximitor Seismic Monitor | Monitors vibration and proximity | 1.1 kg | 24.4 x 241.3 x 100 mm |
| 3500/25 | Enhanced Vibration Monitor | Advanced diagnostics for rotating equipment | 1.2 kg | 24.4 x 241.3 x 100 mm |
| 3500/60 | Keyphasor Module | Provides speed and phase reference | 1.0 kg | 24.4 x 241.3 x 100 mm |
