Product Overview
The Bently Nevada 330905-00-15-05-02-00 3300 NSv Proximity Probe is designed for reliable, high-precision vibration and displacement monitoring in small and medium-sized machinery. As part من the 3300 NSv (Narrow Side-view) series, it is optimized for applications where space is limited but accurate condition monitoring is essential. With its compact probe design and proven proximity measurement technology, this probe provides stable and accurate shaft position data, ensuring machinery protection in critical industries.
Key Features
-
Compact probe design suitable for restricted installation spaces
-
High-accuracy shaft vibration and displacement monitoring
-
Part من the 3300 NSv series for small and mid-size machinery applications
-
Robust construction for harsh industrial environments
-
ممتاز frequency response for dynamic monitoring
-
Compatible with Bently Nevada 3300 monitoring systems
-
Reliable operation across wide temperature ranges
-
Long service life and low maintenance requirements
Technical Specifications
| Item | Specification |
|---|---|
| الشركة المصنعة | Bently Nevada |
| رقم القطعة | 330905-00-15-05-02-00 |
| Product Type | 3300 NSv Proximity Probe |
| Probe Tip Diameter | 5 mm |
| Cable Length | 1.5 m |
| Connector Type | Standard BNC |
| Measurement Range | Up to 2 mm (80 mils) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Frequency Response | DC to 10 kHz |
| Operating Temperature | -35 °C to +175 °C |
| Storage Temperature | -40 °C to +200 °C |
| Total Length | 0.5 meter |
| الوزن | 0.15 kg |
| Mounting Thread | M8 × 1 |
| Humidity | 5–95% RH (non-condensing) |
| System Compatibility | Bently Nevada 3300 NSv Monitoring Systems |
Industry Applications
-
Small steam and gas turbines
-
Compressors and blowers
-
Electric motors and pumps
-
Gearboxes and drive systems
-
Power generation وحدةs
-
Petrochemical and refining equipment
الأسئلة الشائعة (FAQ)
Q1: What is the primary function من the 330905-00-15-05-02-00 probe?
It measures shaft vibration and displacement in small and medium-sized machinery.
Q2: What is the probe tip diameter?
The probe has a 5 mm tip.
Q3: What is the cable length for this probe?
It comes with a 1.5 m cable.
Q4: What is the measurement range?
It supports up to 2 mm (80 mils) من displacement measurement.
Q5: What is the sensitivity من this probe?
The sensitivity is 7.87 V/mm (200 mV/mil).
Q6: What monitoring systems is it compatible with?
It is compatible with Bently Nevada 3300 NSv Monitoring Systems.
Q7: Can it operate in high-temperature environments?
Yes, it operates from -35 °C to +175 °C.
Q8: Is it suitable for compact machinery installations?
Yes, it is specifically designed for use in limited space applications.
