Product Overview
The Bently Nevada 330850-X0-00 3300 XL 25 mm Front Sensor is a heavy-duty proximity probe specifically designed for large shaft machinery where extended linear range and precision are required. As part من the 3300 XL series, it delivers accurate vibration and displacement measurements while maintaining excellent stability in challenging industrial environments.
Key Features
-
25 mm probe tip for extended linear range and shaft displacement monitoring
-
Front mount design for ease من installation and maintenance
-
High immوحدةy to electrical noise (EMI/RFI) for reliable operation
-
Fully compatible with the 3300 XL system including Proximitor® sensors and extension cables
-
Durable stainless-steel housing designed for harsh environments
-
Wide operating temperature range for demanding industrial applications
Technical Specifications
| Item | Specification |
|---|---|
| الطراز Number | 330850-X0-00 |
| Series | 3300 XL |
| Type | 25 mm Front Mount Proximity Probe |
| Tip Diameter | 25 mm |
| Linear Range | 0.25 to 5.0 mm (10 to 200 mils) |
| Sensitivity | 100 mV/mil (3.94 mV/μm) |
| Frequency Range | 0 to 5 kHz |
| Probe Housing | Stainless steel |
| Cable Length | Configurable (via compatible extension cable) |
| Operating Temperature | -35 °C to +177 °C |
| Storage Temperature | -50 °C to +200 °C |
| Humidity | Up to 100% condensing |
| Dimensions | 81.3 x 35.1 x 58.4 mm |
| الوزن | 0.255 kg |
| Compliance | CE, RoHS |
الأسئلة الشائعة (FAQ)
Q1: What is the function من the 330850-X0-00 sensor?
It measures shaft vibration and displacement for large rotating machinery.
Q2: What is its probe tip size?
It has a 25 mm probe tip.
Q3: What is the linear measurement range?
0.25 to 5.0 mm (10 to 200 mils).
Q4: What sensitivity does it provide?
The probe منfers 100 mV/mil (3.94 mV/μm).
Q5: Is it part من the 3300 XL system?
Yes, it is fully compatible with 3300 XL Proximitor® sensors and extension cables.
Q6: Can it operate in high-temperature environments?
Yes, up to +177 °C in operation and +200 °C in storage.
Q7: Is the probe housing durable?
Yes, it is made from stainless steel for robustness.
Q8: Which mounting configuration does it use?
It is designed for front mount installations.
Q9: Which industries typically use this sensor?
It is used in turbines, compressors, generators, and heavy industrial rotating machinery.
Q10: Can it be interchanged with smaller probes?
Yes, it is interchangeable within the 3300 XL system, though selection depends on shaft size and measurement requirements.
