مقدمة المنتج
The Bently Nevada 330193-09-20-05-00 3300 XL 8 mm Probe is a high-precision, non-contact proximity sensor designed for monitoring rotor vibration, shaft displacement, and overall machinery dynamics in critical industrial equipment. Part من the trusted 3300 XL series, this probe ensures accurate and reliable measurement in challenging environments. Its robust construction, eddy-current sensing technology, and high linearity make it ideal for predictive maintenance, machinery protection, and real-time diagnostic systems in power generation, petrochemical, and heavy industrial applications.
Product Parameters
| Parameter | Specification |
|---|---|
| الطراز | 330193-09-20-05-00 |
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Measurement Range | 2 mm (80 mil) linear range |
| Sensitivity | 7.87 mV/µm (200 mV/mil) |
| Tip Diameter | 8 mm |
| Thread Type | M10 × 1 mm |
| Operating Temperature (Probe) | –35 °C to +200 °C |
| Operating Temperature (Cable/Conn.) | –51 °C to +177 °C |
| Frequency Response | 0 to 10 kHz |
| Vibration Tolerance | Up to 20 g, 10–2000 Hz |
| Shock Tolerance | Up to 200 g peak |
| Environmental Protection | IP67 |
| Total Length | 0.5 meter |
| الوزن | 0.162 kg |
Product Applications
-
Turbines: Real-time monitoring من rotor position and vibration in gas and steam turbines.
-
Compressors & Pumps: Detects rotor imbalance, misalignment, and bearing wear for preventive maintenance.
-
Motors & Generators: Provides accurate vibration and displacement measurements for operational reliability.
-
Industrial Machinery: Suitable for heavy industrial applications where precise shaft monitoring is critical.
Product Advantages
-
High Accuracy: Stable linear output ensures precise measurements across the 2 mm range.
-
Wide Temperature Range: Functions reliably from –35 °C to +200 °C.
-
Robust and Durable: IP67-rated housing protects against dust, moisture, and harsh environmental conditions.
-
Electromagnetic Shielding: Reduces signal interference for consistent measurement output.
-
Shock & Vibration Resistant: Can withstand high vibration and mechanical shock up to 200 g peak.
-
System Compatibility: Integrates seamlessly with Bently Nevada 3300 XL Proximitor® sensors and 3500 series monitoring modules.
FAQ
-
What is the sensitivity من the 330193-09-20-05-00 probe?
The probe provides a sensitivity من 7.87 mV/µm (200 mV/mil), enabling precise monitoring من shaft vibration and displacement. -
Which Bently Nevada systems are compatible with this probe?
It is compatible with 3300 XL Proximitor® sensors and 3500 series monitoring modules for seamless integration. -
What is the operating temperature range for the probe and its cable?
The probe operates from –35 °C to +200 °C, and the cable and connector range is –51 °C to +177 °C. -
How is the probe installed securely on rotating machinery?
It uses an M10 × 1 mm threaded body and locknut for stable mounting near the shaft. -
What measurement principle does the probe use?
The probe uses eddy-current technology to generate a voltage proportional to the distance between the probe tip and shaft surface. -
What level من continuous vibration can the probe handle?
The probe tolerates up to 20 g continuous vibration in the 10–2000 Hz frequency range. -
Is the probe environmentally protected?
Yes, it is IP67-rated, providing protection against dust and temporary water exposure. -
What is the shock tolerance من this probe?
The probe can withstand mechanical shocks up to 200 g peak without affecting performance. -
How is signal integrity maintained in electrically noisy environments?
Shielded construction minimizes electromagnetic interference and temperature-related drift, ensuring reliable signal output. -
Can the probe measure both radial and axial displacement?
Yes, it can measure both radial vibration and axial shaft displacement, enabling comprehensive machinery diagnostics.
Related الطرازs (Same Series or Similar)
| الطراز Number | الوصف |
|---|---|
| 330192-00-30-10-00 | 3300 XL 8 mm ETR Probe for standard vibration monitoring |
| 330192-00-70-05-CN | 3300 XL 8 mm ETR Probe with enhanced temperature tolerance |
| 330192-10-80-90-05 | 3300 XL 8 mm ETR Probe for extended industrial use |
| 330192-10-95-90-05 | 3300 XL 8 mm ETR Probe for heavy-duty equipment |
| 330193-00-02-10-00 | 3300 XL 8 mm Probe with alternate length configuration |
| 330193-00-04-10-00 | 3300 XL 8 mm Probe with standard 1.0 m length |
Popular Bently Nevada الطرازs
| الطراز Number | الوصف |
|---|---|
| 3500/22M | Transient Data Interface Module |
| 3300 XL 5 mm | Proximity Probe for compact installation |
| 3500/42M | Proximitor®/Seismic Monitor |
| 330130-040-00 | Standard Proximitor® Sensor |
| 3500/50 | Tachometer Module |
| 330180-90-05 | 3300 XL 11 mm Proximity Probe for large shaft targets |
