مقدمة المنتج
The Bently Nevada 330171-00-26-10-02-00 is part من the 3300 XL series من 5 mm proximity probes, specifically designed for high-precision vibration and position monitoring من critical rotating machinery. This model excels in harsh industrial environments, such as turbines, compressors, and pumps, where reliable, non-contact measurement من shaft displacement is essential. The reverse mount feature من the probe allows for easier installation and maintenance, especially in confined or challenging spaces.
This probe is compatible with Bently Nevada’s 3300 XL Proximitor® Sensors, forming a complete system for condition-based monitoring من machinery. Its durability and accuracy make it an essential component in the proactive management من plant assets, reducing downtime and preventing costly breakdowns by providing real-time vibration data.
With a measurement range from 0.25 mm to 2.00 mm, and an operating temperature range من -35°C to +177°C, the 330171-00-26-10-02-00 probe is engineered for flexibility and performance in demanding industrial settings. Its designed for easy installation and extended reach, providing further convenience for users in large or complex setups.
Technical Specifications
| Parameter | Details |
| رقم القطعة | 330171-00-26-10-02-00 |
| Product Family | 3300 XL Series |
| Probe Type | 5 mm Proximity Probe (Reverse Mount) |
| Mounting Thread Size | 1/4-28 UNF |
| Total Length | 1 meters |
| Measurement Range | 0.25 mm to 2.00 mm (10 mils to 80 mils) |
| Sensitivity | 7.87 mV/μm (200 mV/mil) typical |
| Linear Range | 2 mm (80 mils) |
| Frequency Response | 0 Hz to 10 kHz |
| Operating Temperature | -35°C to +177°C (-31°F to +351°F) |
| Shock Limit | 100 g peak |
| Vibration Limit | 10 g peak (55–500 Hz) |
| Insulation Resistance | >10 MΩ (probe body to connector) |
| Material – Probe Body | 303 Stainless Steel |
| Material – Cable Jacket | FEP (Fluorinated Ethylene Propylene) |
| Electrical Connector | Coaxial stainless steel overbraid, sealed |
| Environmental Protection | IP65 or better (with proper installation) |
| الوزن | 0.323 kg |
Applications
The 330171-00-26-10-02-00 probe is ideal for non-contact monitoring من rotating machinery in a wide range من applications, including:
-
Steam and Gas Turbines
Monitoring shaft displacement for early detection من imbalance or misalignment. -
Compressors and Pumps
Detecting excessive vibration or position shifts in critical pump and compressor وحدةs. -
Electric Motors
Tracking the position من motor shafts for predictive maintenance. -
Gearboxes
Ensuring proper alignment and condition من gear shafts. -
Blowers and Fans
Monitoring rotor vibrations to prevent potential damage. -
Industrial Skids and OEM Equipment
Providing real-time monitoring for system integrators and custom installations.
The reverse mount feature makes this probe particularly suitable for installations where access is limited, such as retrمنits or when adapting to older systems.
Product Advantages
-
Easy Installation
The reverse mount design allows for flexible and simplified installation, especially in restricted spaces. -
Superior Performance
Offers exceptional linearity, sensitivity, and frequency response, providing highly accurate measurements for critical machinery. -
Wide Operating Temperature Range
The probe can operate in temperatures ranging from -35°C to +177°C, making it suitable for a variety من industrial conditions. -
Electromagnetic Shielding
The stainless steel overbraid and coaxial cable construction ensure minimal interference from electromagnetic noise, leading to reliable data even in electrically noisy environments. -
Compatibility with 3300 XL Proximitor Sensors
This probe seamlessly integrates with Bently Nevada’s 3300 XL series من proximitor sensors, providing a comprehensive solution for machine monitoring. -
Durability and Reliability
Designed for high shock and vibration resistance, ensuring long-lasting performance even in demanding industrial applications. -
High Sensitivity
With a sensitivity من 7.87 mV/μm, the probe منfers detailed and precise measurements, essential for early detection من faults. -
Compliant with Industry Standards
Meets API 670 and CE standards, ensuring compliance with critical industrial monitoring requirements.
Recent أخبار القطاع Headlines
-
“Bently Nevada Announces Enhanced Capabilities for 3300 XL Probes”
New features include improved accuracy and extended temperature ranges. -
“Energy Industry Embraces Proximity Probes for Predictive Maintenance”
Companies adopt 3300 XL probes to minimize downtime and enhance operational efficiency. -
“Bently Nevada’s 3300 Series Probes Revolutionize Turbine Monitoring”
A significant upgrade in vibration monitoring technology for turbines. -
“API 670 Compliance Continues to Drive Demand for Bently Nevada Proximity Probes”
Increasing demand for certified solutions in mission-critical machinery. -
“The Role من Proximity Probes in Preventing Catastrophic Failures in Industrial Plants”
Proximity probes like the 330171-00-26-10-02-00 play a key role in safeguarding plant equipment. -
“Improved Shock Resistance in Bently Nevada’s 3300 Probes Enhances Reliability”
Enhanced durability allows for longer operational life in heavy-duty machinery. -
“Bently Nevada Proximity Probes Ensure Performance and Reliability in Harsh Environments”
Solutions built to withstand extreme conditions in oil and gas applications. -
“New Developments in Machine Monitoring: Bently Nevada Sets the Standard”
Cutting-edge technologies further strengthen Bently Nevada’s position as a market leader.
الأسئلة الشائعة (FAQ)
-
What is the typical application for the 330171-00-26-10-02-00 proximity probe?
It is typically used for monitoring the displacement and vibration من rotating machinery, such as turbines, pumps, and compressors. -
Can this probe be used in hazardous environments?
Yes, with proper installation, it can be used in harsh and hazardous environments, including oil & gas and petrochemical plants. -
What is the maximum operating temperature من this probe?
The probe can operate at temperatures up to +177°C. -
How does the reverse mount design benefit installation?
It allows for installation from the rear من the mounting surface, which is helpful in tight or confined spaces. -
What is the length من the cable, and is it flexible for routing?
The probe comes with a 1 meters cable that is flexible enough for installation in larger or complex systems. -
Is the probe suitable for high-vibration applications?
Yes, the probe is designed to handle high shock and vibration levels up to 100 g peak. -
Does this probe work with other Bently Nevada systems?
Yes, it is fully compatible with Bently Nevada’s 3300 XL Proximitor Sensors and other associated hardware. -
What is the sensitivity من the 330171-00-26-10-02-00 probe?
It has a sensitivity من 7.87 mV/μm, منfering precise measurements for small changes in shaft displacement. -
How منten should the probe be calibrated?
It is recommended to calibrate the probe annually, depending on usage and operational requirements. -
What makes this probe different from the 8 mm version?
The 5 mm version is more compact, making it suitable for smaller shafts and tighter spaces compared to the 8 mm model.
Related الطرازs (Same Series or Function)
| الطراز Number | الوصف | Mount Type | Cable Length | Sensitivity | Application |
| 330171-00-08-90-01-05 | 5 mm Reverse Mount, High Temp Variant | Reverse | 8 ft | 7.87 mV/μm | High temperature applications |
| 330171-00-10-15-05 | 5 mm Probe, For General Monitoring | Reverse | 10 ft | 7.87 mV/μm | General vibration monitoring |
| 330171-00-12-10-02-00 | 5 mm Reverse Mount with Extended Cable | Reverse | 12 ft | 7.87 mV/μm | Extended installations |
| 330171-00-08-08-01-01 | 5 mm Proximity Probe with 8 ft Cable | Reverse | 8 ft | 7.87 mV/μm | Standard machinery monitoring |
| 330100-01-06-10-00 | 5 mm Probe with 6 mm Thread | Front Mount | 10 ft | 7.87 mV/μm | General machinery monitoring |
| 330171-00-15-05-02-00 | 5 mm Proximity Probe with 15 ft Cable | Reverse | 15 ft | 7.87 mV/μm | Extended reach installations |
| 330171-00-08-30-01-00 | 5 mm Reverse Mount, 30 ft Cable | Reverse | 30 ft | 7.87 mV/μm | Large industrial systems |
| 330171-00-20-20-10-00 | 5 mm Probe, High Accuracy Variant | Reverse | 20 ft | 7.87 mV/μm | High-precision monitoring |
Popular Bently Nevada الطرازs
| الطراز Number | الوصف | Mount Type | Cable Length | Sensitivity | Application |
| 330350-01-08-20-00 | 8 mm Proximity Probe | Reverse | 8 ft | 7.5 mV/μm | Vibration monitoring |
| 330180-01-04-12-00 | 4 mm Proximity Probe | Reverse | 12 ft | 10 mV/μm | Light-duty machinery |
| 330300-01-10-14-00 | 10 mm Proximity Probe | Reverse | 14 ft | 8 mV/μm | Heavy-duty equipment |
| 3300 5 mm Probe Assembly | Standard 5 mm Proximity Probe | Front Mount | 12 ft | 7.87 mV/μm | General machinery monitoring |
| 330180-01-05-10-00 | 5 mm High-Precision Probe | Front Mount | 10 ft | 10 mV/μm | Precision monitoring |
| 330350-01-06-05-00 | 6 mm Proximity Probe | Front Mount | 5 ft | 7.5 mV/μm | Small equipment monitoring |
| 330171-00-08-40-01-00 | 8 mm Proximity Probe with 40 ft Cable | Reverse | 40 ft | 7.5 mV/μm | Long distance applications |
| 330400-01-20-00 | 20 mm Proximity Probe | Reverse | 20 ft | 7.5 mV/μm | Heavy machinery monitoring |
