مقدمة المنتج
The Bently Nevada 330104-02-08-50-12-00 3300 XL 8 mm Proximity Probe is a high-precision, non-contact eddy current sensor designed to measure shaft displacement and vibration in critical rotating machinery. As part من the 3300 XL series, this probe delivers accurate and reliable signals to support machine protection, predictive maintenance, and condition monitoring.
With an 8 mm probe diameter and a total cable length من 5 meters, this probe is ideal for medium to large industrial machinery or installations where cable routing flexibility is needed. The stainless steel housing and mineral-insulated cable provide resistance to harsh environmental conditions including vibration, temperature fluctuations, and electromagnetic interference. Designed for seamless integration with Bently Nevada 3300 XL monitoring systems, this probe ensures continuous high-fidelity measurements, enabling early detection من mechanical faults and enhancing overall machinery reliability.
مواصفات المنتج
| Parameter | Specification |
|---|---|
| الطراز Number | 330104-02-08-50-12-00 |
| Product Type | 8 mm Eddy Current Proximity Probe |
| Series | 3300 XL |
| Probe Diameter | 8 mm |
| Total Length | 5 meters |
| Measurement Range | Up to 1.27 mm (dependent on system configuration) |
| Linear Range | ±10% من calibrated gap |
| Frequency Response | DC to 10 kHz |
| Sensitivity | 20 mV/µm (typical with 3300 XL monitoring system) |
| Resolution | <0.5 µm |
| Operating Temperature | -40°C to +120°C (probe head) |
| Storage Temperature | -50°C to +150°C |
| Probe Material | Stainless steel housing with mineral-insulated cable |
| Humidity | 0–95% non-condensing |
| Certifications | CE, UL, CSA |
| الوزن | 1.615 kg |
| Mounting | Threaded sleeve or custom machinery mounting |
| Compatibility | Bently Nevada 3300 XL Series Monitoring Systems |
Applications
The 330104-02-08-50-12-00 probe is suitable for precise measurement من shaft displacement and vibration in critical machinery:
-
Steam and Gas Turbines – Detects rotor imbalance, misalignment, and instability.
-
Compressors – Monitors rotor vibration and shaft position to ensure safe and efficient operation.
-
Pumps – Identifies cavitation, bearing wear, and shaft deflection.
-
Generators and Motors – Provides early detection من anomalies for reliable operation.
-
Refinery and Petrochemical Plants – Performs under high-vibration, harsh environmental conditions.
-
Machine Protection Systems – الدعمs API 670-compliant condition monitoring and protection.
Advantages
The Bently Nevada 330104-02-08-50-12-00 8 mm Probe منfers several operational advantages:
-
High Accuracy – Delivers precise shaft displacement and vibration measurement with excellent linearity.
-
Rugged Construction – Stainless steel housing and mineral-insulated cable ensure durability in harsh industrial environments.
-
Wide Frequency Response – Captures both low-speed and high-speed shaft vibrations.
-
Seamless System Integration – Fully compatible with 3300 XL monitoring systems for continuous machine protection.
-
Maintenance-Free Operation – Non-contact measurement eliminates wear and reduces maintenance requirements.
-
Temperature and Vibration Resistant – Reliable performance under extreme conditions.
-
Predictive Maintenance الدعم – Early anomaly detection helps prevent unplanned downtime.
-
Flexible Installation – 5-meter cable length supports complex machinery layouts or larger equipment.
الأسئلة الشائعة (FAQ)
-
Which monitoring systems is this probe compatible with?
The probe is designed for full integration with Bently Nevada 3300 XL monitoring systems, providing reliable displacement and vibration signals. -
What is the nominal sensitivity من this probe?
The probe typically outputs 20 mV/µm when used with a 3300 XL system. -
What is the frequency range that the probe can measure?
It operates from DC to 10 kHz, suitable for detecting low-speed and high-speed vibrations. -
What is the operating temperature range من the probe head?
Reliable performance is maintained between -40°C and +120°C. -
Can the probe function in high-humidity or industrial environments?
Yes, it is rated for 0–95% non-condensing humidity and designed for harsh industrial conditions. -
What is the linear measurement range من the probe?
The linear range is ±10% من the calibrated gap, ensuring accurate output. -
Does the probe require external power?
No, power and signal conditioning are provided by the 3300 XL monitoring system. -
Is this probe suitable for API 670-compliant machine protection systems?
Yes, it is compatible with API 670-compliant condition monitoring and protection systems. -
Does the 5-meter cable affect measurement accuracy?
The probe is calibrated for a 5-meter cable, maintaining high-fidelity signal output. -
What are the recommended mounting options?
Threaded sleeve or custom machinery mounting ensures proper alignment and calibration.
Related الطرازs (Same Series)
| الطراز Number | Probe Type | الوصف |
|---|---|---|
| 330104-02-08-50-12-01 | 8 mm Proximity Probe | Standard 3300 XL probe with 3-meter cable |
| 330104-02-08-50-12-02 | 8 mm Proximity Probe | High-temperature variant |
| 330104-02-08-50-12-03 | 8 mm Proximity Probe | Extra-flexible cable version |
| 330105-02-08-50-12-00 | 8 mm Proximity Probe | High-sensitivity configuration |
| 330106-02-08-50-12-00 | 8 mm Proximity Probe | API 670-compliant variant |
| 330104-02-08-50-12-04 | 8 mm Proximity Probe | Extended linear range version |
Popular الطرازs from the Same العلامة التجارية (Bently Nevada)
| الطراز Number | Product Type | الوصف |
|---|---|---|
| 330104-01-09-50-01 | 8 mm Proximity Probe | Standard 3300 XL probe for turbines and compressors |
| 330104-01-09-50-03 | 8 mm Proximity Probe | High-accuracy probe for critical machinery |
| 330105-01-09-50-01 | 8 mm Proximity Probe | High-sensitivity version for vibration monitoring |
| 330130-01-09 | 3300 XL Proximity Probe | Compact probe for smaller machinery |
| 330140-01-09 | 3300 XL Proximity Probe | Extended range probe for large turbines |
| 330150-01-09 | 3300 XL Proximity Probe | API 670-compliant probe for generators |
