Product Overview
The Bently Nevada 330103-00-04-50-02-05 is a high-performance 8 mm proximity probe designed as part من the 3300 XL series. Engineered for precision and durability, this probe is used in condition monitoring and machinery protection systems for critical rotating assets. With a calibrated range من 50 mils (1.27 mm), it is ideal for applications requiring slightly extended linear measurement capabilities compared to standard 40-mil probes.
This non-contact sensor measures the distance between the probe tip and a rotating shaft or other conductive targets, providing real-time displacement and vibration data to help detect misalignment, imbalance, or mechanical wear.
Key Features
-
8 mm sensing tip with 50-mil linear measurement range
-
Calibrated for consistent, linear output
-
Compatible with Bently Nevada 3300 XL extension cables and Proximitor sensors
-
Stainless steel body with high durability and corrosion resistance
-
Threaded body for secure and adjustable installation (M16 × 1.5 mm)
-
EMI/RFI shielding ensures reliable signal integrity
-
Designed to operate reliably in harsh industrial conditions
-
Fully backward compatible with legacy 3300 systems
Technical Specifications
| Parameter | Specification |
|---|---|
| الطراز Number | 330103-00-04-50-02-05 |
| Product Series | Bently Nevada 3300 XL |
| Probe Tip Diameter | 8 mm |
| Linear Range | 1.27 mm (0.050 in or 50 mils) |
| Sensing Range | 0.25 mm to 2.54 mm (0.010 in to 0.100 in) |
| Sensitivity | 7.87 mV/μm (200 mV/mil) nominal |
| System Accuracy | ±0.07 mm (±0.0028 in) over linear range |
| Output Signal Type | Voltage (proportional to gap distance) |
| Mounting Thread | M16 × 1.5 mm |
| Connector Type | 10-pin male Bendix connector |
| Cable Length | 10 meters (32.8 feet) |
| Probe Body Material | Stainless steel |
| Vibration Limit | 20 g peak, 10–2000 Hz |
| Shock Limit | 500 g peak |
| Operating Temperature | -40 °C to +120 °C |
| Storage Temperature | -51 °C to +177 °C |
| Environmental Rating | IP65 (when properly installed) |
| Dimensions | Total Length: 5.0 meters |
| الوزن | 1.615 kg |
Typical Applications
-
Monitoring من large rotating machinery such as turbines, compressors, and motors
-
Measurement من shaft displacement and vibration in real-time
-
Preventive maintenance in oil & gas, power generation, and chemical processing plants
-
Axial position monitoring in critical process equipment
-
Integration with Bently Nevada 3500 and legacy 3300 systems
-
Use in high-vibration or high-temperature industrial environments
-
Predictive diagnostics for minimizing unscheduled downtime
-
الحالة monitoring من pumps, blowers, fans, and gearboxes
Advantages
-
Extended Measurement Range: 50-mil linear span is ideal for applications with wider clearances or larger shaft movements
-
High Reliability: Proven performance under extreme temperature, vibration, and shock conditions
-
Easy Integration: Works seamlessly with the full 3300 XL product ecosystem
-
Modular Design: Enables simple field replacement and flexible installation
-
Precision Monitoring: Accurate vibration and position feedback for predictive maintenance
-
Rugged Construction: Stainless steel housing and sealed design resist corrosion and contamination
-
Reduced Maintenance Costs: Non-contact sensing avoids mechanical wear
-
Industrial Compliance: Engineered to meet global performance and safety standards
الأسئلة الشائعة (FAQ)
-
What is the linear measurement range من this probe?
This model is calibrated for a 50-mil (1.27 mm) linear range, slightly higher than the standard 40 mils. -
What equipment is this probe typically used with?
It pairs with Bently Nevada 3300 XL extension cables and Proximitor sensors and is used in vibration monitoring من rotating machines. -
Is the 10-meter cable length fixed?
No, other cable lengths can be configured at the time من ordering. -
What mounting is used for this probe?
It features a threaded body with an M16 × 1.5 mm thread for adjustable and secure installation. -
Is this model suitable for hazardous environments?
The probe itself is rugged, but hazardous location use depends on the full system configuration and certifications. -
What type من signal does the probe generate?
It generates an analog voltage signal proportional to the distance between the probe tip and the target surface. -
Can it be used with legacy Bently Nevada systems?
Yes, the 3300 XL series is backward-compatible with 3300 series monitoring systems. -
What is the tip diameter من the probe?
The sensing tip diameter is 8 mm. -
Does this model have EMC shielding?
Yes, it is shielded against EMI and RFI to ensure signal integrity. -
What is the typical service life?
When properly installed and maintained, these probes are designed for long-term use, منten exceeding 5–10 years in the field.
Related and Recommended الطرازs
| الطراز Number | الوصف |
|---|---|
| 330103-00-04-40-02-05 | 3300 XL 8 mm Probe with 40-mil linear range |
| 330103-00-04-20-02-05 | 3300 XL 8 mm Probe, standard range |
| 330104-00-05-10-01-00 | 3300 XL 8 mm Probe with armored cable |
| 330101-00-14-10-02-05 | 3300 XL High-Temperature 8 mm Probe |
| 330130-040-00-00 | 3300 XL Extension Cable, 4 meters |
| 330180-90-00 | 3300 XL Proximitor Sensor |
Popular Bently Nevada الطرازs
| الطراز Number | الوصف |
|---|---|
| 3500/42M | Proximitor Monitor for Shaft Vibration |
| 3500/22M | Transient Data Interface Module |
| 3300 XL Proximitor Sensor | Converts probe signal for system monitoring |
| 7200 Series | Proximitor and Velocity Sensors |
| 990-04-70-01-00 | Velocity Transducer for General Machinery |
| 3500/15 | Power Supply Module for 3500 System |
