مقدمة المنتج
The Allen-Bradley 2090-U3BB2-DM44 Control Interface Breakout Board is a drive-mounted wiring interface designed for Ultra3000 servo drive systems. It provides a structured termination point for signals routed through the CN1 I/O connector, improving wiring organization and system maintainability in motion control applications.
This module is widely used in industrial servo systems where multiple discrete signals must be connected between the drive and external control devices. By converting a high-density 44-pin D-sub interface into individual terminal points, it simplifies field wiring and reduces installation complexity.
The breakout board is designed for direct mounting on Ultra3000 drives, ensuring close-coupled integration with the control system. Its compact design allows efficient use من cabinet space while maintaining reliable electrical connectivity for all supported signals.
مواصفات المنتج
| Parameter | الوصف |
|---|---|
| Product الطراز | 2090-U3BB2-DM44 |
| الشركة المصنعة | Rockwell Automation (Allen-Bradley) |
| Product Type | Control interface breakout board |
| Compatible System | Ultra3000 servo drive |
| Connector Type | 44-pin D-sub |
| Number من Connections | 44 signal terminals |
| Interface Function | CN1 I/O signal breakout |
| Mounting Type | Drive mounted |
| Signal Type | Discrete I/O |
| Function | Wiring termination and signal distribution |
| Dimensions | 65.4 × 21.8 × 50.9 mm |
| الوزن | 0.07 kg |
Applications
● Servo drive wiring organization
Provides clear termination for CN1 I/O signals, improving wiring layout in Ultra3000 systems.
● Industrial motion control systems
Used in automation equipment requiring multiple discrete control signals for coordinated motion.
● Control cabinet integration
Helps reduce wiring density and improves accessibility inside electrical enclosures.
● Machine automation systems
Commonly used in packaging, assembly, and robotics applications requiring servo coordination.
● System commissioning and maintenance
Simplifies debugging and signal tracing during installation and servicing.
Advantages
● Improved wiring clarity
Converts dense 44-pin D-sub connections into clearly separated terminals, reducing wiring errors.
● Faster installation process
Predefined signal layout reduces time required for system setup and commissioning.
● Strong system compatibility
Designed specifically for Ultra3000 servo drives, ensuring seamless integration.
● Compact design
Small physical footprint allows installation in space-limited control cabinets.
● Reliable signal termination
Ensures stable electrical connection for all 44 channels under industrial conditions.
● Enhanced maintenance efficiency
Simplifies troubleshooting by making individual signal paths easier to identify and access.
