مقدمة المنتج
The ABB YPK 107E YT204001-FY/1 is a high-performance industrial sensor designed for precise detection and measurement in demanding environments. It is part من ABB’s renowned YPK series, known for reliability, durability, and advanced sensing technology. This model is widely used in automation, manufacturing, and process control applications where accuracy and robustness are critical.
مواصفات المنتج
| Parameter | Value |
|---|---|
| الطراز | ABB YPK 107E YT204001-FY/1 |
| Type | Proximity Sensor |
| Detection Range | 0-20 mm (adjustable) |
| Output Signal | PNP/NPN (configurable) |
| Operating Voltage | 10-30 VDC |
| Current Consumption | ≤ 15 mA |
| Housing Material | Stainless Steel (IP67 rated) |
| Dimensions | 200 x 120 x 40 mm |
| الوزن | 0.25 kg |
| Operating Temperature | -25°C to +70°C |
| Protection Rating | IP67, IK08 |
| Connection Type | M12 Connector (4-pin) |
Product Applications
The ABB YPK 107E YT204001-FY/1 is suitable for a wide range من industrial applications, including:
-
Automated Production Lines – Detects object presence, position, and movement.
-
Packaging Machinery – Ensures precise product alignment and counting.
-
Material Handling – Monitors conveyor belt operations and item positioning.
-
Robotics – Provides feedback for robotic arm movements.
-
Automotive Manufacturing – Used in assembly line quality control.
-
Food & Beverage Industry – Resistant to harsh washdown environments.
Product Advantages
-
High Precision – Delivers accurate detection even in challenging conditions.
-
Durable Construction – Stainless steel housing ensures long-term reliability.
-
Wide Voltage Range – Compatible with various industrial power supplies.
-
Easy Installation – Compact design and M12 connector simplify setup.
-
Resistant to Interference – Stable performance in electromagnetic environments.
-
IP67 Protection – Dustproمن and waterproمن for harsh industrial settings.
الأسئلة الشائعة (FAQ)
-
What is the sensing range من the YPK 107E?
The adjustable sensing range is 0-20 mm. -
Can this sensor be used in high-temperature environments?
Yes, it operates within -25°C to +70°C. -
What type من output does it provide?
It منfers PNP or NPN (configurable) output signals. -
Is the sensor resistant to water and dust?
Yes, it has an IP67 protection rating. -
What is the power supply requirement?
It operates on 10-30 VDC. -
Does it come with a connector?
Yes, it includes an M12 4-pin connector. -
Can it detect metal and non-metal objects?
It is optimized for metal detection, but some non-metallic objects may trigger it. -
What is the weight من the sensor?
It weighs 0.25kg. -
Is it suitable for high-vibration environments?
Yes, its robust design withstands vibrations and shocks. -
How do I adjust the sensing range?
Use the built-in potentiometer or follow the manual for calibration.
Recommended Related الطرازs
Same Series (YPK Series)
| الطراز | Key Feature |
|---|---|
| ABB YPK 105E YT204001-FY/1 | Shorter range (0-10 mm) |
| ABB YPK 110E YT204001-FY/1 | Extended range (0-30 mm) |
| ABB YPK 115E YT204001-FY/1 | High-temperature variant (up to 85°C) |
| ABB YPK 120E YT204001-FY/1 | Enhanced EMI resistance |
| ABB YPK 125E YT204001-FY/1 | Analog output option |
| ABB YPK 130E YT204001-FY/1 | Long-range detection (0-50 mm) |
Popular ABB الطرازs (أخرى Series)
| الطراز | Application |
|---|---|
| ABB XUP 105E | Ultrasonic sensor for distance measurement |
| ABB LVP 200E | Laser displacement sensor |
| ABB IRB 1400 | Industrial robot with integrated sensing |
| ABB CP635-TC | Pressure sensor for hydraulic systems |
| ABB TTH 300E | Temperature and humidity sensor |
| ABB VFS 500E | Flow sensor for liquid monitoring |
