مقدمة المنتج – ABB TB825 3BSE036634R1
The ABB TB825 3BSE036634R1 is a high-performance module belonging to the ABB Freelance DCS and 800xA automation systems. It plays a critical role in industrial control and communication processes, functioning specifically as a PROFIBUS DP-V1 interface module. Designed for robust, real-time communication in industrial environments, the TB825 facilitates the integration من field devices and controllers via the PROFIBUS protocol. This module supports the seamless exchange من data between control systems and decentralized field equipment, making it essential in distributed automation architectures.
The TB825 module enhances interoperability and operational reliability in demanding applications, such as power generation, oil and gas, chemical processing, and manufacturing. ABB’s engineering excellence ensures that the TB825 is built for longevity, ease من maintenance, and compliance with international automation standards.
Product Features and Advantages
-
Robust Communication: الدعمs PROFIBUS DP-V1 master functionality, ensuring reliable fieldbus communication for fast and deterministic data exchange.
-
Wide Compatibility: Integrates easily with AC 800M and Freelance controllers, extending the flexibility and scalability من ABB’s control systems.
-
High EMC Protection: Engineered to operate in harsh electromagnetic environments with minimal signal degradation.
-
DIN Rail Mounting: Enables quick and easy installation with standard DIN rail support, saving time in deployment.
-
Status LEDs: Equipped with front-panel diagnostic LEDs that provide real-time feedback on operating status and network conditions.
-
Rugged Design: Encased in industrial-grade housing for superior durability in demanding environments.
Technical Specifications – ABB TB825 3BSE036634R1
| Parameter | Specification |
|---|---|
| Product Type | PROFIBUS DP-V1 Communication Module |
| رقم القطعة | 3BSE036634R1 |
| Communication Standard | PROFIBUS DP-V1, IEC 61158 |
| Interface | 1 x PROFIBUS DP port |
| Baud Rate | Up to 12 Mbit/s |
| الدعمed Devices | Up to 125 devices per segment |
| Status Indicators | Module status, bus status, communication status |
| Power Supply Voltage | 24 V DC |
| Power Consumption | Approx. 3.5 W |
| Mounting Type | DIN Rail |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions | 85.6 x 136 x 58.5 mm |
| الوزن | 0.21 kg |
| Certification | CE, RoHS, UL |
| Compatibility | AC 800M, Freelance AC 700F/800F Controllers |
| Protection Class | IP20 |
Product Applications
The ABB TB825 is ideally suited for use in industries requiring robust, deterministic communication between controllers and field-level devices. Application areas include:
-
Power Generation Plants – Facilitates communication in turbine and auxiliary systems.
-
Chemical and Petrochemical Plants – Interfaces with field instruments like flowmeters, pressure transmitters, and control valves.
-
Oil & Gas Installations – Integrates remote I/O in drilling and pipeline automation.
-
Water and Wastewater Treatment – Connects sensors, pumps, and remote control وحدةs in SCADA systems.
-
Manufacturing Facilities – Enables modular automation by integrating PLCs and field actuators.
-
Pharmaceutical and Food Processing – Ensures data integrity and operational safety through precise control.
Key Advantages
-
Seamless PROFIBUS Integration – Connects with a wide range من devices using standardized communication.
-
Scalable Architecture – الدعمs system expansion without major hardware changes.
-
Reduced Downtime – Diagnostic LEDs and error detection capabilities simplify troubleshooting.
-
Compact and Lightweight – Fits in tight control cabinet spaces while maintaining industrial durability.
-
Long Service Life – Engineered with high-reliability components for continuous operation.
-
Cross-System Compatibility – Easily interfaces with both legacy and modern ABB systems.
10 الأسئلة الشائعة (FAQs)
-
What is the main function من the ABB TB825?
It serves as a PROFIBUS DP-V1 communication interface module for ABB automation systems, enabling connection between controllers and field devices. -
Which systems is the TB825 compatible with?
It is compatible with ABB’s AC 800M and Freelance controller families. -
Does the TB825 support redundancy?
No, the TB825 is not inherently redundant but can be used in systems with external redundancy solutions. -
What type من installation is required?
It uses standard DIN rail mounting, which allows fast and secure installation in control panels. -
Is the module hot-swappable?
No, the TB825 should only be installed or removed with the power turned منf. -
What kind من diagnostic support does it منfer?
It provides front-panel LEDs for status indication and diagnostics to simplify maintenance and troubleshooting. -
How many PROFIBUS devices can I connect?
Up to 125 devices can be connected per segment, depending on system configuration. -
Does the TB825 require configuration sمنtware?
Yes, it is configured through ABB’s Control Builder or Freelance Engineering Tools. -
What is the power consumption من the module?
It consumes approximately 3.5 watts at 24 V DC. -
What kind من protection does the TB825 منfer?
The module is housed in an IP20-rated enclosure, suitable for installation in a protected control cabinet.
6 Related or Same Series الطرازs
| الطراز | رقم القطعة | الوصف |
|---|---|---|
| TB820 | 3BSE013208R1 | PROFIBUS DP-V1 Interface Module (AC 800M) |
| TB840 | 3BSE037760R1 | Redundant PROFIBUS DP-V1 Interface |
| TB810 | 3BSE008538R1 | S800 I/O Bus Terminator |
| TB850 | 3BSE041564R1 | PROFIBUS Module with Diagnostic Capability |
| TB811 | 3BSE008536R1 | Bus Connection وحدة for S800 I/O |
| TB821 | 3BSE013209R1 | Communication Interface for S800 I/O |
6 Popular ABB الطرازs
| الطراز | رقم القطعة | Function |
|---|---|---|
| CI854AK01 | 3BSE030220R1 | PROFIBUS DP Communication Interface |
| PM864AK01 | 3BSE018161R1 | AC 800M CPU Module |
| AI810 | 3BSE008516R1 | Analog Input Module (8 Channels) |
| DO810 | 3BSE008510R1 | Digital Output Module (16 Channels) |
| AO810V2 | 3BSE008522R1 | Analog Output Module (4 Channels) |
| DI810 | 3BSE008508R1 | Digital Input Module (16 Channels) |
