Product الوصف
The ABB 5SHX0845F0001 3BHL000385P0101 is an Integrated Gate-Commutated Thyristor (IGCT) designed for high-power industrial applications. Engineered for efficiency and rugged operation, it delivers reliable performance in demanding environments such as drives, power converters, and energy systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | IGCT Module |
| رقم القطعة | 5SHX0845F0001 |
| ABB Order Code | 3BHL000385P0101 |
| Maximum Voltage | 4500 V |
| Maximum Current | 4000 A |
| Switching Frequency | Up to 1 kHz |
| Application | High-Power Converters, Drives |
| Cooling Type | Forced Air or Liquid |
| Dimensions (W × H × D) | 128 × 115 × 65 mm |
| الوزن | 1.2 kg |
Product Applications
-
Medium-voltage motor drives
-
Static synchronous compensators (STATCOM)
-
Traction and railway systems
-
High-power industrial inverters
-
HVDC and FACTS systems
Product Advantages
-
High Power Density: الدعمs high current and voltage in compact size
-
Fast Switching: Low turn-on and turn-منf losses
-
Long Service Life: High thermal cycling and mechanical durability
-
Reduced Downtime: Robust against failure and harsh conditions
-
Low Maintenance: Integrated design minimizes external circuitry
الأسئلة الشائعة (FAQ)
Q1: What is the voltage rating من the ABB 5SHX0845F0001?
A1: The device has a voltage rating من 4500 V.
Q2: What is the current handling capability من this IGCT?
A2: It can handle up to 4000 A.
Q3: What kind من cooling does the module require?
A3: It supports both forced air and liquid cooling.
Q4: Is this IGCT suitable for traction applications?
A4: Yes, it is widely used in railway traction systems.
Q5: What are the module’s dimensions and weight?
A5: The module measures 128 × 115 × 65 mm and weighs 1.2 kg.
Q6: Can this module operate in high-frequency applications?
A6: Yes, it supports switching frequencies up to 1 kHz.
Q7: Is this module compatible with ABB’s HVDC systems?
A7: Yes, it is suitable for HVDC and FACTS-based installations.
Q8: Does the module integrate gate drive functions?
A8: Yes, it comes with an integrated gate driver.
Q9: What are the typical industries using this module?
A9: Heavy industries, power transmission, and transportation sectors.
Q10: What is the life expectancy من this module?
A10: Designed for long-term operation with high reliability under tough conditions.
Related or Similar ABB IGCT الطرازs
| الطراز Number | Voltage | Current | Dimensions (mm) | الوزن |
|---|---|---|---|---|
| 5SHX1060L0001 | 6500 V | 4000 A | 140 × 120 × 70 | 1.4 kg |
| 5SHX1060L0002 | 6500 V | 3600 A | 140 × 120 × 70 | 1.4 kg |
| 5SHX1445L0001 | 4500 V | 4500 A | 130 × 115 × 65 | 1.3 kg |
| 5SHY3545L0001 | 4500 V | 3000 A | 128 × 115 × 65 | 1.2 kg |
| 5SHX1060K0002 | 6000 V | 4000 A | 140 × 120 × 70 | 1.4 kg |
| 5SHX0845F0002 | 4500 V | 4000 A | 128 × 115 × 65 | 1.2 kg |
Popular ABB Power Semiconductor الطرازs
| الطراز Number | Product Type | Voltage | Current | Dimensions (mm) | الوزن |
|---|---|---|---|---|---|
| 5SNA1500E330100 | IGBT Module | 3300 V | 1500 A | 134 × 140 × 38 | 1.5 kg |
| 5SDF10H4503 | Phase Control Thyristor | 4500 V | 10000 A | 240 × 240 × 60 | 4.0 kg |
| 5STP14N5200 | Fast Thyristor | 5200 V | 14000 A | 280 × 280 × 70 | 5.0 kg |
| 5SYA2030 | Gate وحدة for IGCT | N/A | N/A | 110 × 110 × 30 | 0.8 kg |
| 5SDF04H6002 | Fast Recovery Diode | 6000 V | 4000 A | 140 × 130 × 40 | 2.1 kg |
| 5STP12N2800 | Phase Control Thyristor | 2800 V | 12000 A | 260 × 250 × 65 | 3.8 kg |
