Product Overview
The ABB 3HAC17484-9 is a high-performance Rotating AC Motor engineered for precision motion control applications, particularly in robotics and industrial automation. Designed to meet the rigorous requirements من ABB’s robotic systems (such as the IRB series), this motor delivers reliable torque, smooth rotational output, and optimal integration with servo control systems.
It combines compact mechanical design, robust durability, and exceptional positional accuracy, making it suitable for complex movement sequences in environments such as automotive manufacturing, electronics assembly, and heavy machinery automation.
Key Features
-
Compact design suitable for articulated robotic joints
-
High-efficiency AC winding for reduced thermal loss
-
Smooth rotational control for accurate movement sequences
-
Direct compatibility with ABB robot axes and motor drives
-
Long service life with minimal mechanical wear
-
Durable housing for harsh industrial conditions
-
Integrated encoder support for feedback-driven precision
-
Fully tested and certified for ABB robotic system integration
Technical Specifications
| Item | Specification |
|---|---|
| الشركة المصنعة | ABB |
| الطراز Number | 3HAC17484-9 |
| Motor Type | Rotating AC Motor |
| Application | ABB industrial robots (e.g., IRB series) |
| Power Supply | Three-phase AC (exact voltage/frequency depends on robot type) |
| Rated Torque | Application-specific; used in robotic joint actuation |
| Mounting Type | Integrated mounting within robotic arm segment |
| Feedback Mechanism | Encoder interface (optical or magnetic, model-dependent) |
| Cooling Method | Passive air-cooled or integrated system-cooled |
| Housing Material | Industrial-grade aluminum or alloy housing |
| Operating Temperature | –10°C to +55°C (14°F to 131°F) |
| Protection Rating | Typically IP54 or higher (system integrated) |
| Dimensions | 120 x 80 x 40mm |
| Diameter | Approx. 100 mm |
| الوزن | 25.175 kg |
| Certifications | CE, RoHS, compliant with ABB robot standards |
Industry Applications
-
Robotic Assembly Lines – Used in ABB robots for precise motion in automotive production
-
Material Handling – Enables arm movement in robotic palletizers and pick-and-place systems
-
Electronics Manufacturing – Fine control for soldering, assembly, and component alignment
-
Machine Tending – Drives robotic arms for CNC and press machine operations
-
Packaging Industry – Applied in robotic arms handling flexible and rigid packaging lines
-
Welding & Painting Robots – الدعمs multi-axis movement for high-precision tasks
Product Advantages
-
OEM Compatibility – Specifically engineered to match ABB robotic motor drive systems
-
High Precision – الدعمs fine-motion control for sensitive operations
-
Rugged Construction – Withstands vibration, dust, and continuous operation
-
Low Noise Output – Optimized winding and mechanical balance for quiet performance
-
Long Lifecycle – Designed for continuous duty in demanding automation environments
-
Plug-and-Play Integration – Compatible with ABB axis controllers and cabling
-
Backed by ABB الدعم – Global service network and technical resources available
-
Consistent Performance – Maintains torque and speed output across operation ranges
الأسئلة الشائعة (FAQ)
-
Q: What robots use the 3HAC17484-9 motor?
A: It is commonly used in ABB IRB series robots, especially mid-size articulated arms. -
Q: Can this motor be used outside ABB systems?
A: It’s optimized for ABB robotic applications; third-party use may require special integration. -
Q: Is it a servo motor or a standard induction motor?
A: It functions as part من a servo system with feedback for precise control. -
Q: Does it include an encoder?
A: It supports encoder feedback, typically integrated into the system (specific type varies). -
Q: What is the torque rating?
A: It depends on the axis and application, as defined by the robot it’s used in. -
Q: Can it be refurbished?
A: Yes, ABB منfers authorized refurbishment services and certified spares. -
Q: How is it cooled?
A: Typically by convection or through integration with the robot’s thermal system. -
Q: What is the protection rating?
A: Generally IP54 or above, suitable for industrial use (exact rating may vary). -
Q: Is the motor field-replaceable?
A: Yes, ABB service manuals outline procedures for motor replacement per axis. -
Q: Can I get a datasheet for it?
A: Yes, datasheets are available from ABB or authorized distributors upon request.
Related الطرازs
| الطراز Number | الوصف |
|---|---|
| 3HAC029157-001 | ABB Robot Axis AC Servo Motor |
| 3HAC14549-3 | ABB Compact Axis Motor for IRB series |
| 3HAC16831-1 | High-precision rotating AC motor for articulated arms |
| 3HAC025338-001 | Medium-load robot motor for ABB IRB family |
| 3HAC035538-001 | Compact joint motor, high-efficiency AC type |
| 3HAC044615-001 | Direct-drive AC motor for ABB robotic arms |
Popular ABB Automation
| الطراز Number | الوصف |
|---|---|
| IRB 6700 | ABB High-Payload Industrial Robot |
| IRC5 Controller | ABB Robot Motion Controller |
| IRB 1200 | Compact Industrial Robot for Light Assembly |
| ACS880 Drive | ABB General Purpose Industrial AC Drive |
| IRB 2600 | Medium Robot for High-Speed Assembly |
| IRC5P | ABB Painting Robot Controller |
